13998 Festo Pneumatic Valves Accessories

13998 on Powermatic Associates
Festo

Part#:13998

Alt. Part#:NAV-1/4-NPT-1C

Manufacturer:Festo

Category:Pneumatic Valves Accessories

Product Lifecycle:Active

Product description

manifold sub-base NAV-1/4-NPT-1C With port pattern as per DIN ISO 5599/1, for manifold assembly, connections underneath. Width: 110 mm, Operating pressure: 16 bar, Operating medium: Compressed air in accordance with ISO8573-1:2010 [7:-:-], Note on operati

Product Details

  • Operating pressure
    16 bar
  • Operating medium
    Compressed air as per ISO 8573-1:2010 [7:-:-]
  • Type code
    NAV
  • Width
    110 mm
  • Ambient temperature
    -10 °C ... 60 °C
  • Pilot air port 14
    NPT1/8-27
  • Pneumatic connection 4
    NPT1/4-18
  • Temperature of medium
    -10 °C ... 60 °C
  • Information on operating and pilot media
    Operation with oil lubrication possible (required for further use)
  • Pilot air port 12
    NPT1/8-27
  • Sub-base mounting type
    With through-hole
  • Pneumatic connection 2
    NPT1/4-18

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

13998 Related Documents

13998 DataSheet.pdf
