132891 Festo Pneumatic Fittings

132891 on Powermatic Associates
Festo

Part#:132891

Alt. Part#:QSL-V0-1/8-4

Manufacturer:Festo

Category:Pneumatic Fittings

Product Lifecycle:Active

Product description

push-in L-fitting QSL-V0-1/8-4 360° orientable, male thread with external hexagon. Size: Standard, Nominal size: 2,8 mm, Material fire test: (* UL94 V-0 (housing), * UL94 V-0 (releasing ring)), Type of seal on screw-in stud: coating, Design structure: Pus

Product Details

  • Maritime classification
    See certificate
  • Nominal width
    2.8 mm
  • Type code
    QSL-V0
  • Size
    Standard
  • Material fire test
    UL94 V-0 (housing) UL94 V-0 (releasing ring)
  • Design
    Push-pull principle
  • Operating medium
    Compressed air as per ISO 8573-1:2010 [7:-:-] Water as per manufacturer's declaration at www.festo.com
  • Product weight
    11 g
  • Note on materials
    RoHS-compliant
  • Housing material
    PBT-reinforced
  • Material of screwed trunnion
    Brass, nickel-plated
  • Type of seal on screwed trunnion
    Coating
  • Information on operating and pilot media
    Operation with oil lubrication possible
  • Corrosion resistance class (CRC)
    2 - Moderate corrosion stress
  • Pneumatic connection 1
    R1/8
  • Releasing ring color
    Black
  • Operating pressure for entire temperature range
    -0.95 bar ... 10 bar
  • Ambient temperature
    0 °C ... 60 °C
  • Pneumatic connection 2
    for pneumatic tubing outside diameter 4 mm

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

132891 Related Documents

132891 DataSheet.pdf
