10802 Festo Flow Control Valves

Product Details

• Pneumatic connection 2
  PK-3
• Operating pressure
  0 bar ... 8 bar
• Symbol
  00991453
• Standard flow rate in non-return direction at 6 -> 0 bar
  127 l/min
• Product weight
  48 g
• Adjusting element
  Rotary knob with scale
• Standard nominal flow rate in flow control direction
  40.7 l/min
• Note on materials
  Contains paint-wetting impairment substances RoHS-compliant
• Type code
  GRP
• Actuation type
  Manual
• Ambient temperature
  -10 °C ... 50 °C
• Standard flow rate in flow control direction 6 -> 0 bar
  60 l/min
• Information on operating and pilot media
  Operation with oil lubrication not possible
• PK connections material
  Wrought aluminum alloy Brass
• Pneumatic connection 1
  PK-3
• Type of mounting
  Front panel mounting
• Housing material
  PA-reinforced
• Operating pressure from 2 to 1
  0 bar ... 8 bar
• Standard nominal flow rate in flow control direction from 1bar to 0 bar
  19 l/min
• Temperature of medium
  -10 °C ... 50 °C
Seals material
NBR PVC
Valve function
Flow control non-return function
Standard nominal flow rate in non-return direction
88 l/min
Mounting position
Any
Standard nominal flow rate in non-return direction from 1 bar to 0 bar
20 l/min ... 60 l/min
Operating medium
Compressed air as per ISO 8573-1:2010 [5:4:3] Inert gas
Retaining bracket material
Wrought aluminum alloy
Material of screws
Steel
