M22-K10 Eaton Industrial Automation Components

M22-K10 on Powermatic Associates
Eaton

Part#:M22-K10

Manufacturer:Eaton

Category:Industrial Automation Components

Product Lifecycle:Active

Only 4 left in stock. Order Now!

Apr 14, 2025

Product description

M22-K10 Eaton - Eaton M22 Contact Block, 22.5 mm, Front, Screw, Button: Black, NO, IP66, NEMA 4X, 13

Product Details

  • Weight
    .04 pounds
  • Size
    22.5 millimeters
  • Type
    Contact Block
  • Length
    1.25 inches
  • Enclosure Material
    Stainless Steel
  • Height
    0.25 inches
  • Actuator
    Front, Screw
  • Contact Configuration
    NO
  • Contact Configuration:
    1NC
  • Contact Rating:
    500 Volt AC 2 Amp
  • Terminal Type:
    Screw Clamp
  • Contact Material:
    Silver Alloy
  • Catalog:
    Eaton_32247_V7T1_46_V7T1_47_V7T1_49_V7T1_51_V7T1_53_V7
  • Mounting:
    Front
  • UPC:
    786685278001
  • Series:
    M22
  • Size:
    22.5 Millimeter
  • Color:
    Black
  • Shipping Height:
    2.00 In.
  • Shipping Weight:
    0.05 lbs.
  • Shipping Length:
    2.00 In.
  • Shipping Width:
    1.00 In.
  • Material:
    Phenolic/Polycarbonate

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
