WLS28-2XR145DXQ Banner Light Bars

WLS28-2XR145DXQ on Powermatic Associates
Banner

Part#:WLS28-2XR145DXQ

Manufacturer:Banner

Category:Light Bars

Alt. Part#:93091

Product Lifecycle:Active

Get a quick Quote!

WLS28-2 Work Light Strip; Diffuse Window; Length: 145 mm; Voltage: 12-30 V dc; Environmental Rating: IP50; Color: Red; 4-pin M12 Integral QD

About the manufacturer: Banner is one of the manufacturers that offers Light Bars that you can order at Powermatic Associates site. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.

Check out the WLS28-2XR145DXQ Banner price in the box on the right side or send a quick quote.

Product Details

  • Weight
    272.1552 g
  • Country Of Origin
    MX
  • Pro-Editor Compatible (Discrete)
    No
  • Wireless
    No
  • Modbus RTU
    No
  • IO Link
    No
  • Feature: Chemical Resistant
    No
  • Feature: Audible
    No
  • Min Op. Temperature (°C)
    -40
  • Feature: Hazardous Area
    No
  • Primary Window Material
    Polycarbonate Diffused
  • Storage Temp (°C)
    -40 to 70
  • Max Op. Temperature (°C)
    70
  • Supply Voltage
    12-30 V dc
  • Environmental Rating
    IP50
  • Illuminated Length (LxWxH mm)
    145.0
  • Physical Dimensions (LxWxH or DxH mm)
    186.0 x 28.0 x 20.9
  • Quick Disconnect Type
    M12 (Euro)
  • Dimming Option
    High-Low-Off
  • Number of Input Pins/Conductors
    4
  • Color 1 - Wavelength/Color Temp/Coordinates
    625 nm
  • Lumens Color 1
    245
  • Connection
    Integral QD
  • Animation Option 1
    Solid On
  • Color Option 1
    Red
  • Color Technology
    Standard LED
  • Product Size (mm)
    28
  • Color Input Control
    Individual (One wire/color, same number of colors as input wires)
  • Number of Colors / Segments
    1
  • Mounting Thread
    No Thread
  • Housing Style
    Linear Strip
  • Illumination
    Yes
  • Primary Housing Material
    Aluminum
  • Power
    DC
  • Power Source
    DC

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

WLS28-2XR145DXQ Description

Banner Engineering WLS28-2XR145DXQ is a task light designed as an LED industrial strip light/bar with a diffused plastic window for 1-color Red LED illumination. It operates on a supply voltage range of 12Vdc to 30Vdc, with a nominal voltage of 24Vdc. The dimensions of this product are L145mm x W28mm, featuring a polycarbonate (PC) window and an aluminium housing for durability. It is pre-equipped with a 4-pin M12 Euro-style QD connector for easy connection. This linear light strip is designed for surface or wall mounting and has an IP50 degree of protection, making it suitable for environments where dust protection is necessary. It can operate in ambient air temperatures ranging from -40°C to +70°C. Additionally, it includes 1 x digital input (12-30Vdc) for color control and offers a luminous flux of 245 lm (lumens).

Related documents WLS28-2XR145DXQ Specs

WLS28-2XR145DXQ 175008.pdf
