WLB32C1130PBQ

Banner

Product Lifecycle: Active

Banner Engineering WLB32C1130PBQ is a cascadable industrial LED workstation task light bar designed for a variety of lighting needs. It features a high/low/off switch and provides 1-color Daylight White (DW) LED illumination. This product operates on a supply voltage range of 12Vdc to 30Vdc, with a nominal voltage of 24Vdc. The dimensions of this linear lighting are L1130mm x W32mm, and it is constructed with a polycarbonate (PC) diffused window and an aluminium housing for durability. It comes pre-equipped with a 4-pin M12 Euro-style quick disconnect (QD) connector for easy installation. The WLB32C1130PBQ offers a degree of protection rated at IP50 and can operate in ambient air temperatures ranging from -40°C to +70°C. It includes 1 x digital input (12Vdc / 24Vdc) for color control, consumes 3.2A of current, and delivers a luminous flux of 3000 lm (lumens).

WLB32C1130PBQ

Banner Engineering WLB32C1130PBQ is a cascadable industrial LED workstation task light bar designed for a variety of lighting needs. It features a high/low/off switch and provides 1-color Daylight White (DW) LED illumination. This product operates on a supply voltage range of 12Vdc to 30Vdc, with a nominal voltage of 24Vdc. The dimensions of this linear lighting are L1130mm x W32mm, and it is constructed with a polycarbonate (PC) diffused window and an aluminium housing for durability. It comes pre-equipped with a 4-pin M12 Euro-style quick disconnect (QD) connector for easy installation. The WLB32C1130PBQ offers a degree of protection rated at IP50 and can operate in ambient air temperatures ranging from -40°C to +70°C. It includes 1 x digital input (12Vdc / 24Vdc) for color control, consumes 3.2A of current, and delivers a luminous flux of 3000 lm (lumens).

WLB32C1130PBQ.pdf

WLB32 Industrial LED Light Bar (DC).pdf

WLB32C1130PBQ.stp

Product details

WLB32C1130PBQ.pdf

WLB32 Industrial LED Light Bar (DC).pdf

WLB32C1130PBQ.stp

WirelessNo
Feature: CascadeYes
Primary Window MaterialPolycarbonate Diffused
Pro-Editor Compatible (Discrete)No
Modbus RTUNo
Feature: Chemical ResistantNo

IO LinkNo

Feature: AudibleNo

Illumination Switch FunctionI=Low; O=OFF; II=High

Feature: Hazardous AreaNo

Storage Temp (°C)-40 to 70

Min Op. Temperature (°C)-40

Environmental RatingIP50

Max Op. Temperature (°C)70

Physical Dimensions (LxWxH or DxH mm)1166.0 x 31.9 x 46.0

Illuminated Length (LxWxH mm)1130.0

Number of Input Pins/Conductors4

Supply Voltage12-30 V dc

Dimming OptionHigh-Low-Off

Color 1 - Wavelength/Color Temp/Coordinates5000K (Daylight)

Lumens Color 13000

Quick Disconnect TypeM12 (Euro)

ConnectionIntegral QD

Animation Option 1Solid On

Color TechnologyStandard LED

Product Size (mm)32

Color Input ControlIndividual (One wire/color, same number of colors as input wires)

Number of Colors / Segments1

Color Option 1White

Mounting ThreadNo Thread

Primary Housing MaterialAluminum

IlluminationYes

Power SourceDC

Housing StyleLinear Strip

PowerDC

This part can ship within 24 hours

$310.00

Stock:

2

Select Qty:

$310.00

$310.00 each
