WLS27XW570DSQ Banner Signal Towers

WLS27XW570DSQ on Powermatic Associates
Banner

Part#:WLS27XW570DSQ

Alt. Part#:94277

Manufacturer:Banner

Category:Signal Towers

Product Lifecycle:Active

Only 4 left in stock. Order Now!

Mar 31, 2025

Product description

WLS27 Work Light Strip; Diffused Window; Length: 570 mm; Voltage: 12-30 V dc; Environmental Rating: IP66; IP67; IP69K; Color: White; 4-pin M12 Integral QD

Product Details

  • Weight
    453.592 g
  • Country Of Origin
    MX
  • Pro-Editor Compatible (Discrete)
    No
  • Wireless
    No
  • Modbus RTU
    No
  • IO Link
    No
  • Multi-Color Device
    Single Color On
  • Feature: Hazardous Area
    No
  • Feature: Chemical Resistant
    Yes
  • Feature: Audible
    No
  • Primary Window Material
    Copolyester Diffused
  • Feature: Washdown Rated
    Yes
  • Storage Temp (°C)
    -40 to 70
  • Min Op. Temperature (°C)
    -40
  • Max Op. Temperature (°C)
    70
  • Environmental Rating
    IP66; IP67; IP69
  • Physical Dimensions (LxWxH or DxH mm)
    27.0 x 633.5
  • Illuminated Length (LxWxH mm)
    570.0
  • Supply Voltage
    12-30 V dc
  • Lumens Color 1
    1600
  • Number of Input Pins/Conductors
    4
  • Connection
    Integral QD
  • Color 1 - Wavelength/Color Temp/Coordinates
    6500K (Cool)
  • Dimming Option
    High-Low-Off
  • Max Current Color (mA)
    1600
  • Color Option 1
    White
  • Quick Disconnect Type
    M12 (Euro)
  • Animation Option 1
    Solid On
  • Color Technology
    Standard LED
  • Illumination
    Yes
  • Number of Colors / Segments
    1
  • Mounting Thread
    No Thread
  • Color Input Control
    Individual (One wire/color, same number of colors as input wires)
  • Housing Style
    Linear Strip
  • Primary Housing Material
    FDA Copolyester
  • Product Size (mm)
    27
  • Power
    DC
  • Power Source
    DC

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of WLS27XW570DSQ on Powermatic Associates is $352.00. Order now.

About the product

Banner Engineering WLS27XW570DSQ is a single color series industrial sealed LED task light designed for a variety of applications. This task light features a diffused window for 1-color White LED illumination and operates on a supply voltage of 12Vdc to 30Vdc, with a nominal voltage of 24Vdc. It measures L570mm x D27mm, with a cylindrical linear strip shape and a 27mm tube diameter. The material used includes a copolyester diffused window and FDA-grade copolyester for the outer housing, ensuring durability. It comes pre-equipped with a 4-pin M12 Euro-style QD connector for easy connection. This model offers a high degree of protection with ratings of IP66, IP67, and IP69K, making it suitable for harsh environments. It can operate in ambient air temperatures ranging from -40°C to +70°C. The WLS27XW570DSQ also features 1 x digital input (12-30Vdc) for color control, consumes 1.6A of current, and provides a luminous flux of 1600 lm (lumens).
