WLS27XWGRYB5-0570DS24Q Banner Signal Towers

Product Details

• Weight
  453.592 g
• Country Of Origin
  MX
• Wireless
  No
• Modbus RTU
  No
• Feature: Hazardous Area
  No
• Primary Window Material
  Copolyester Diffused
• Feature: Washdown Rated
  Yes
• Max Op. Temperature (°C)
  50
• Pro-Editor Compatible (Discrete)
  No
• IO Link
  No
• Feature: Audible
  No
• Multi-Color Device
  Single Color On
• Feature: Chemical Resistant
  Yes
• Min Op. Temperature (°C)
  -40
• Storage Temp (°C)
  -40 to 70
• Environmental Rating
  IP66; IP67; IP69
• Physical Dimensions (LxWxH or DxH mm)
  27.0 x 633.5
• Illuminated Length (LxWxH mm)
  570.0
• Supply Voltage
  24 V dc
• Max Current Color (mA)
  800
Number of Input Pins/Conductors
4
Animation Option 4
Solid On
Color 5 - Wavelength/Color Temp/Coordinates
470 nm
Lumens Color 5
250
Color Option 5
Blue
Animation Option 5
Solid On
Color 2 - Wavelength/Color Temp/Coordinates
525 nm
Animation Option 3
Solid On
Color 4 - Wavelength/Color Temp/Coordinates
580 nm
Lumens Color 4
1140
Color Option 3
Red
Lumens Color 2
800
Animation Option 2
Solid On
Color Option 4
Yellow
Color 3 - Wavelength/Color Temp/Coordinates
625 nm
Lumens Color 3
370
Color Option 2
Green
Color Technology
Standard LED
Quick Disconnect Type
M12 (Euro)
Color Option 1
White
Color 1 - Wavelength/Color Temp/Coordinates
5000K (Daylight)
Lumens Color 1
1300
Connection
Integral QD
Animation Option 1
Solid On
Product Size (mm)
27
Number of Colors / Segments
5
Mounting Thread
No Thread
Housing Style
Linear Strip
Indication
Yes
Primary Housing Material
FDA Copolyester
Power
DC
Color Input Control
Multiple (One or more wires/color, enables more colors than input wires)
Illumination
Yes
Power Source
DC
Cable Length (m)
0.15
