TTR457RPSA6C-2.0FL-CTR Banner Safety Light Curtains
Part#:TTR457RPSA6C-2.0FL-CTR
Alt. Part#:810324
Manufacturer:Banner
Category:Safety Light Curtains
Product Lifecycle:Active
Product description
TTR Series 6 Beam Sensor Array Diffuse; Resolution: 54 mm; Range: 120 mm; Input: 18-30 V dc Output: DO PNP; 2 m (6.5 ft) Cable Flying Leads
Product Details
- Weight 322.05032 g
- Country Of Origin MX
- Number of Beams 6
- Distance to First Beam [mm] 93.5
- Max Op. Temperature (°C) 55
- Operation Dark Operate
- Beam to Beam Spacing [mm] 54
- NEMA Rating N/A
- IP Rating IP50
- Delay at Power-up (ms) 1500
- Max Op. Relative Humidity (%) 95% @ 55°C
- Min Op. Temperature (°C) -10
- Indicator Indicator LEDs
- Lens Material Polycarbonate
- Special Feature: Remote Teach No
- Adjustments N/A
- Output response time (ms) 1
- Number of Pins 4
- Outputs PNP
- Power Supply/Supply Voltage 18-30 V dc
- Slot Overall Depth (mm) 19
- Quick Disconnect Type No QD
- Cable Length (m) 2
- Sensing Mode (Detailed) Diffuse
- Connection Cable
- Primary Housing Material Black Anodized Aluminum
- Housing Style Sensing Array Bar
- Slot Depth/Array Length (mm) 457
- End Cap Type C: Adj Hex / Spring 11 mm Hex - 8 mm Round
- Max Sensing Range (mm) 120
- Power DC
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of TTR457RPSA6C-2.0FL-CTR on Powermatic Associates is $215.00. Order now.
About the product
Banner Engineering TTR457RPSA6C-2.0FL-CTR is a sensor array designed in a diffuse mode with 6 beams. This part features a pre-wired connection with a 2m cable and bare end flying leads. It has a rectangular shape with dimensions including a 457mm array length and 54mm beam spacing/pitch. The supply voltage required for operation ranges from 18Vdc to 30Vdc, with a nominal voltage of 24Vdc. It is capable of operating in ambient air temperatures ranging from -10 to +70°C and offers a degree of protection rated at IP50. The sensor provides 1 x digital output (PNP transistor) and has a sensing distance of 120mm. It utilizes infrared (IR) light with a wavelength of 940 nm for detection.
