T186UE W/30 Banner Ultrasonic Sensors

Name: T186UE W/30
Brand: Banner

Banner T186UE W/30 T18U Series: Emitter; Range: 300-600 mm; Input: 12-30 V dc; Output: Not Applicable; 9 m (30 ft) Cable

Part#:T186UE W/30

Manufacturer:Banner

Alt. Part#:40096

Product Lifecycle:Active

Get a quick Quote!

T18U Series: Emitter; Range: 300-600 mm; Input: 12-30 V dc; Output: Not Applicable; 9 m (30 ft) Cable

About the manufacturer: Banner is one of the manufacturers that offers Ultrasonic Sensors that you can order at Powermatic Associates site. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.

Check out the T186UE W/30 Banner price in the box on the right side or send a quick quote.

Product Details

Weight
571.52592 g
Country Of Origin
US
Wireless
No
Profibus
No
1-wire Serial Interface
No
SSI
No
RS-485
No
RS-422
No
Common Ethernet Protocol
No
RS-232
No
PROFINET
No
IO Link
No
Feature: Timing (Hold/Delay)
No
Application: Ultrasonic
Yes
Feature: Chemical Resistant
No
Feature: Clear Object Detection
Yes
Supply Protection Circuitry
Protected against reverse polarity and transient overvoltages
Power/Current Consumption (exclusive of load)
50 mA
Barrel Diameter (mm)
18
Rep Rate (ms)
Normal Resolution Mode: 8; High Resolution Mode: 5

Ultrasonic Frequency (kHz)

230

Temp. Warm-up Drift (Notes 2)

After 25 min, the sensing position will be stable.

Minimum Response Time (ms)

Temperature Warm-up Drift upon Power-up

< 1.7% of the sensing distance upon power-up.

Temp. Warm-up Drift (Notes 1)

After 10 min, the apparent distance is < 0.3% of the actual position.

Min Operating Temperature (°C)

-40

NEMA Rating

NEMA 6P

Mechanical Shock (Additional Comments)

MIL-STD-202G, Meth. 213B, conditions H&I (Shock: 75G with unit operation: 100G for non-operation).

Max Operating Temperature (°C)

IP Rating

IP67

Mechanical Shock

IEC 60947-5-2 requirements: 30G 11 ms duration, half sine wave

Vibration

MIL-STD-202F req. Method 201A (vibration:10 to 60Hz max., double amplitude 0.06", max acc. 10G).

Minimum Sensing Distance (mm)

300

Delay at Power-up (ms)

100

Number of Pins

Power Supply

12-30 V dc

Indicator

LED(s)

Max Sensing Distance (mm)

600

Quick Disconnect Type

No QD

Connection

Flying Leads

Primary Housing Material

PBT

Device Type

Sensor

Cable Length (m)

Housing Style

Rectangular w/M18 Mount

Sensing Mode (Detailed)

Emitter

Sensing Mode (General)

Opposed

PC Configurable

Power

Sensing Beam

Ultrasonic

Max Measurement Range

>500 mm - <=1000 mm

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

T186UE W/30 Description

Banner Engineering T186UE W/30 is an ultrasonic sensor belonging to the T18U series, designed with a through-beam system or opposed mode. This sensor functions as an emitter alone, housed in a thermoplastic material. It features a pre-wired connection with a 30ft / 9m cable terminated with bare end flying leads. The T186UE W/30 operates on a supply voltage range of 12Vdc to 30Vdc, with a nominal voltage of 24Vdc, and is mounted using an M18 threaded mount. It is designed to operate within an ambient air temperature range of -40 to +70°C and offers a degree of protection rated at IP67 NEMA 6P. The sensor has a rectangular shape, a sensing distance between 300mm and 600mm, and operates at a transmission frequency of 230kHz.
