SLM30N6Q-18233 Banner Retroreflective Sensors

SLM30N6Q-18233 on Powermatic Associates
Banner

Part#:SLM30N6Q-18233

Alt. Part#:18233

Manufacturer:Banner

Category:Retroreflective Sensors

Product Lifecycle:Active

Product description

SLM Series: Rugged Nickel-Plated Metal Fixed-Distance Slot Sensor; Slot Width: 30 mm; Input 10-30 V dc; Output: NPN; 3-pin M8 Integral QD; Adhesive added to pot legs

Product Details

  • Weight
    90.7184 g
  • Country Of Origin
    CN
  • Shape
    Slot
  • Material
    Nickel-plate die-cast Zinc housing Acrylic lns.
  • Equivalent to
    SLM30N6Q18233
  • Main function
    Sensor (Photo-electric)
  • Functions
    Photo-electric rugged metal slot / optical fork sensor green LED (power ON) yellow LED (output state) potentiometer adjustment
  • Compliant with standard(s)
    cULus Listed CE
  • Net Height (mm)
    80 mm
  • Supply voltage (DC)
    10Vdc-30Vdc (12Vdc / 24Vdc nom.)
  • Response time
    0.5ms / 0.0005 s
  • Digital outputs
    1 x digital output (NPN transistor)
  • Sub-range name
    SLM series
  • Degree of protection
    IP67 NEMA 6
  • Ambient air temperature for operation
    -20...+60 °C
  • Net Width (mm)
    (passageway) 30 mm62 mm
  • Primary brand
    Banner Engineering
  • Connection type
    Pre-equipped with 3-pin Pico-style M8 connector
  • Operating mode
    Light-ON Dark-ON
  • Order code / Manufacturer SKU
    18233
  • Net Depth (mm)
    12 mm

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of SLM30N6Q-18233 on Powermatic Associates is $184.00. Order now.

About the product

Banner Engineering SLM30N6Q-18233 is a photo-electric rugged metal slot/optical fork sensor from the SLM series, featuring a potentiometer adjustment with adhesive added to pot legs for precise control. It is constructed with a nickel-plated die-cast Zinc housing and an Acrylic lens, ensuring durability. This sensor is pre-equipped with a 3-pin Pico-style M8 connector for easy installation. It operates on a supply voltage of 10Vdc to 30Vdc, with nominal values of 12Vdc and 24Vdc. Designed to function in ambient air temperatures ranging from -20 to +60°C, it offers a degree of protection rated at IP67 NEMA 6, making it suitable for challenging environments. The sensor has a slot (U-shaped) shape with a passageway width of 30mm and an overall width of 62mm, a height of 80mm, and a depth of 12mm. It features 1 x digital output (NPN transistor), a sensing distance of 30mm, and a rapid response time of 0.5ms / 0.0005 s. The operating modes include Light-ON and Dark-ON, providing flexibility for various applications.

SLM30N6Q-18233 Related Documents
