EX-26A-PN Panasonic Retroreflective Sensors

Panasonic EX-26A-PN Panasonic EX-26A-PN is a small-spot beam ultra-compact photoelectric sensor designed for side sensing. It features a PBT housing and a polyarylate lens, with an operating ambient air temperature range of -25 to +55°C and a degree of protection rated at IP67. This sensor emits red light with a wavelength of 650 nm and can detect objects as small as 0.1mm. It is equipped with an orange LED for operation indication and a green LED for stability indication. The EX-26A-PN offers a quick response time of 500µs / 0.0005 s and includes 1 x digital output (PNP open-collector / 24Vdc / 50mA) for connectivity. It operates in Light-ON mode within a sensing distance of 0.6cm to 1.4cm (6mm-14mm). The sensor is connected via a pre-wired 2m 3-core 0.1mm2 flexible cabtyre cable terminated with bare end flying leads.
Panasonic

Part#:EX-26A-PN

Manufacturer:Panasonic

Product Lifecycle:Active

In-stock parts: 3

Sep 28, 2024

Panasonic EX-26A-PN is a small-spot beam ultra-compact photoelectric sensor designed for side sensing. It features a PBT housing and a polyarylate lens, with an operating ambient air temperature range of -25 to +55°C and a degree of protection rated at IP67. This sensor emits red light with a wavelength of 650 nm and can detect objects as small as 0.1mm. It is equipped with an orange LED for operation indication and a green LED for stability indication. The EX-26A-PN offers a quick response time of 500µs / 0.0005 s and includes 1 x digital output (PNP open-collector / 24Vdc / 50mA) for connectivity. It operates in Light-ON mode within a sensing distance of 0.6cm to 1.4cm (6mm-14mm). The sensor is connected via a pre-wired 2m 3-core 0.1mm2 flexible cabtyre cable terminated with bare end flying leads.

About the manufacturer: Panasonic is one of the manufacturers that offers Retroreflective Sensors that you can order at Powermatic Associates site. Panasonic is a leading supplier of cutting-edge automation control solutions that are both advanced and cost-effective. With a significant presence in a variety of industrial sectors globally, including automotive, semiconductor, packaging, and OEMs, our product lineup features PLCs, HMI, and other offerings.

Check out the EX-26A-PN Panasonic price in the box on the right side or send a quick quote.

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

This item can ship within 24h!

Manufacturer warranty

$104.00

Stock:

3

Select Qty:

$104.00

$104.00 each

Worldwide Shipping and Delivery

Secure Payment Processing

Warranty

Responsive Customer Support
