S22DLBXXPQ Banner Pick-to-Light Sensors

S22DLBXXPQ on Powermatic Associates
Banner

Part#:S22DLBXXPQ

Alt. Part#:86138

Manufacturer:Banner

Category:Pick-to-Light Sensors

Product Lifecycle:Active

Product description

S22 Daylight Visible EZ Light - 22 mm - IP67; Single Color: Blue; 10-30 V dc PNP Input; 4-pin M12 Integral QD

Product Details

  • Weight
    54.43104 g
  • Country Of Origin
    CN
  • Pro-Editor Compatible (Discrete)
    No
  • Modbus RTU
    No
  • Wireless
    No
  • IO Link
    No
  • Feature: Chemical Resistant
    No
  • Feature: Quick Disconnect
    Yes
  • Indication Intensity
    High Brightness & Daylight Visible
  • Multi-Color Device
    Single Color On
  • Primary Window Material
    Polycarbonate Clear
  • Feature: Hazardous Area
    No
  • Feature: Washdown Rated
    Yes
  • Min Op. Temperature (°C)
    -40
  • Primary Housing Color
    Black
  • Feature: Audible
    No
  • Max Op. Temperature (°C)
    50
  • NEMA Type and UL Type Rating
    NEMA and UL 4X, 13
  • Environmental Rating
    IP67; IP69
  • Physical Dimensions (LxWxH or DxH mm)
    26.0 x 35.3
  • Max Input Response Time (ms)
    1
  • Input Type
    PNP
  • Supply Voltage
    10-30 V dc
  • Number of Input Pins/Conductors
    4
  • Max Current Color (mA)
    25
  • Quick Disconnect Type
    M12 (Euro)
  • Color 1 - Wavelength/Color Temp/Coordinates
    470 nm
  • Lumens Color 1
    0.60
  • Connection
    Integral QD
  • Animation Option 1
    Solid On
  • Color Technology
    Standard LED
  • Color Option 1
    Blue
  • Product Size (mm)
    22
  • Primary Housing Material
    Polycarbonate
  • Indication
    Yes
  • Number of Colors / Segments
    1
  • Mounting Thread
    M22 x 1.5
  • Color Input Control
    Individual (One wire/color, same number of colors as input wires)
  • Housing Style
    Barrel Mount - Flat Window
  • Cable Length (m)
    0.15
  • Power
    DC
  • Power Source
    DC

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of S22DLBXXPQ on Powermatic Associates is $36.00. Order now.

About the product

Banner Engineering S22DLBXXPQ, part of the EZ-LIGHT series, is a pilot light designed with daylight-visible 1-color blue LED illumination. This product features a clear Polycarbonate (PC) window and a Polycarbonate (PC) base, with a 22mm indicator diameter. It comes pre-equipped with a 4-pin M12 Euro-style QD connector for connectivity. The housing is black, and it operates on a supply voltage range of 10Vdc-30Vdc (12Vdc-24Vdc nom.). For mounting, it utilizes a flush (22mm hole) M22 thread method. The S22DLBXXPQ is designed to operate within an ambient air temperature range of -40°C to +50°C and offers a degree of protection rated at IP67, IP69K, NEMA 4X, NEMA 13, UL type 4X, and UL type 13. Its shape is characterized by a flat window and a threaded cylindrical barrel, with a current consumption of 25mA. Additionally, it includes 1 x digital input (10-30Vdc; PNP) for color control.
