WLS15CDW0360DSC2 Banner Electronic Components

Banner WLS15CDW0360DSC2 Banner Engineering WLS15CDW0360DSC2 is a task light designed as a cascadable sealed industrial low power LED light strip/bar. It features a diffused window for 1-color Daylight White (DW) LED illumination. This product operates on a supply voltage of either 12Vdc or 24Vdc and has dimensions of L360mm x W15mm. The material used for both the diffused window and the base is Polycarbonate (PC), ensuring durability. It comes pre-wired with a 2m / 6.5ft 2-wire cable terminated with bare end flying leads for easy installation. The linear light strip is designed to withstand harsh conditions, with a degree of protection rated at IP66 and IP67. It can operate in ambient air temperatures ranging from -40°C to +60°C. Additionally, it includes 1 x digital input (12Vdc / 24Vdc) for color control, consumes 480mA of current, and provides a luminous flux of 350 lm (lumens).
Banner

Part#:WLS15CDW0360DSC2

Manufacturer:Banner

Product Lifecycle:Active

In-stock parts: 2

Sep 28, 2024

Banner Engineering WLS15CDW0360DSC2 is a task light designed as a cascadable sealed industrial low power LED light strip/bar. It features a diffused window for 1-color Daylight White (DW) LED illumination. This product operates on a supply voltage of either 12Vdc or 24Vdc and has dimensions of L360mm x W15mm. The material used for both the diffused window and the base is Polycarbonate (PC), ensuring durability. It comes pre-wired with a 2m / 6.5ft 2-wire cable terminated with bare end flying leads for easy installation. The linear light strip is designed to withstand harsh conditions, with a degree of protection rated at IP66 and IP67. It can operate in ambient air temperatures ranging from -40°C to +60°C. Additionally, it includes 1 x digital input (12Vdc / 24Vdc) for color control, consumes 480mA of current, and provides a luminous flux of 350 lm (lumens).

About the manufacturer: Banner is one of the manufacturers that offers Electronic Components that you can order at Powermatic Associates site. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.

Check out the WLS15CDW0360DSC2 Banner price in the box on the right side or send a quick quote.

Product Details

  • IO Link
    No
  • Modbus RTU
    No
  • Pro-Editor Compatible (Discrete)
    No
  • Feature: Hazardous Area
    No
  • Wireless
    No
  • Feature: Quick Disconnect
    No
  • Feature: Chemical Resistant
    No
  • Feature: Cascade
    Yes
  • Feature: Audible
    No
  • Storage Temp (°C)
    -40 to 70
  • Secondary Material
    Polyamide
  • Primary Window Material
    Polycarbonate Diffused
  • Min Op. Temperature (°C)
    -40
  • Max Op. Temperature (°C)
    60
  • Environmental Rating
    IP66; IP67
  • Supply Voltage
    12/24 V dc
  • Illuminated Length (LxWxH mm)
    286.4
  • Physical Dimensions (LxWxH or DxH mm)
    360.0 x 30.6 x 15.5
  • Max Current Color (mA)
    480
  • Color Option 1
    White
  • Dimming Option
    PWM
  • Product Size (mm)
    15
  • Color 1 - Wavelength/Color Temp/Coordinates
    5000K (Daylight)
  • Connection
    Cable
  • Number of Colors / Segments
    1
  • Primary Housing Material
    Polycarbonate
  • Power
    DC
  • Color Input Control
    Individual (One wire/color, same number of colors as input wires)
  • Number of Input Pins/Conductors
    2
  • Lumens Color 1
    350
  • Color Technology
    Standard LED
  • Housing Style
    Linear Strip
  • Power Source
    DC
  • Mounting Thread
    No Thread
  • Cable Length (m)
    0.15
  • Illumination
    Yes

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

Related documents WLS15CDW0360DSC2 Specs

WLS15CDW0360DSC2 WLS15C_0360.pdf
WLS15CDW0360DSC2 WLS15C_0360.stp

This item can ship within 24h!

Manufacturer warranty

$85.00

Stock:

2

Select Qty:

$85.00

$85.00 each
