MQLH-815-MF Banner Electronic Components

MQLH-815-MF on Powermatic Associates
Banner

Part#:MQLH-815-MF

Manufacturer:Banner

Category:Electronic Components

Product Lifecycle:Active

Product description

Euro-Style QD Cable with Shield for LH Series, 8-Pin Straight Connectors, Double Ended Male and Female, 5 m (15 ft) in Length, Chrome-plated brass coupling nut

Product Details

  • Feature: Hazardous Area
    No
  • Secondary Orientation
    Straight
  • Secondary Number of Conductors
    8
  • Oil/Grease Resistant
    No
  • Secondary AWG
    24
  • Primary AWG
    24
  • Secondary Connector Type
    EURO
  • Primary Number of Conductors
    6
  • Secondary Gender
    Male
  • Secondary Coupling Method
    M12 Single Key
  • Primary Orientation
    Straight
  • Primary Gender
    Female
  • Primary Coupling Method
    M12 Single Key
  • IP Rating
    IP67
  • Primary Connector Type
    EURO
  • Voltage Rating (V)
    60 V ac/75 V dc
  • Current Rating (A)
    2.0
  • Minimum Temp. (°C)
    -40
  • Maximum Temp. (°C)
    105
  • Coupling Material/Color
    Nickel Plated Brass
  • Cordset Length (m)
    4.57
  • Shield/No Shield
    Shield
  • Trunk Length (m)
    No Trunk
  • Shield Type
    Pin
  • Connector Body Material/Color
    PUR Black
  • Cable Jacket Color
    Black
  • Cable Jacket Material
    PVC
  • Number of Connectors
    2
  • Outside Cable Diameter (mm)
    6
  • Number of Contacts
    8

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
