Banner MAE4816Q MAE4816Q 16CH 2-STICK MA EMITTER
Banner

Part#:MAE4816Q

Manufacturer:Banner

Alt. Part#:72200

Product Lifecycle:Active

Get a quick Quote!

MAE4816Q 16CH 2-STICK MA EMITTER

About the manufacturer: Banner is one of the manufacturers that offers Measurement Sensors that you can order at Powermatic Associates site. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.

Check out the MAE4816Q Banner price in the box on the right side or send a quick quote.

Product Details

  • Weight
    2104.66688 g
  • Country Of Origin
    MX
  • Max Temp (°C)
    70
  • Power Supply
    16-30V dc
  • Housing Length (mm)
    1298
  • Max Relative Humidity
    95%
  • Emitter/Receiver Range (m)
    0.9 - 13.5
  • Discrete Output
    N/A
  • Minimum Object Sensitivity (mm)
    25.4-38.1
  • Array Length (mm)
    1210
  • IO Link
    No
  • RS-232
    No
  • Min Temp (°C)
    -40
  • Number of Beams
    64
  • Analog Output
    N/A
  • RS-485
    No
  • Modbus RTU
    No
  • Sensing Mode (Detailed)
    Emitter
  • Power
    DC
  • Device Type
    Two-Piece
  • Beam Spacing
    19 mm
  • DeviceNet
    No
  • Primary Housing Material
    Aluminum
  • Primary brand
    Banner Engineering
  • Supply voltage (DC)
    16Vdc-30Vdc (24Vdc nom.)
  • Dimensions
    1210mm array length
  • Main function
    Sensor (Edge)
  • Distance
    3/4" / 19mm beam spacing/pitch
  • Material
    Aluminium housing
  • Sub-range name
    MINI-ARRAY 2-piece models
  • Degree of protection
    IP65 UL type 1
  • Order code / Manufacturer SKU
    72200
  • Ambient air temperature for operation
    -40...+70 °C
  • Product series / family name
    A-GAGE series
  • Functions
    Measuring light screen array emitter red LED (status)
  • Detectable object size
    25.4-38.1mm
  • Connection type
    Pre-wired with 6" / 150mm PVC pigtal terminated with M12 Mini-style connector
  • Resolution
    3/4" / 19mm

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

MAE4816Q Description

Banner Engineering MAE4816Q is a sensor from the MINI-ARRAY 2-piece models series designed for measuring light screen array functions, specifically as an emitter alone. This part features a 1210mm array length with a rectangular shape and is constructed with an aluminium housing. It has a beam spacing/pitch of 3/4" / 19mm and comes pre-wired with a 6" / 150mm PVC pigtail that terminates with an M12 mini-style connector. The MAE4816Q operates on a supply voltage of 16Vdc-30Vdc, with 24Vdc as the nominal voltage, and can function within an ambient air temperature range of -40 to +70°C. It offers a degree of protection rated at IP65 UL type 1 and is capable of sensing distances from 90cm to 13.5m. The resolution stands at 3/4" / 19mm, making it suitable for detecting object sizes between 25.4mm and 38.1mm.

Related documents MAE4816Q Specs

MAE4816Q 119169.pdf
