K50BCLGA230Q Banner Pick-to-Light Sensors

Name: K50BCLGA230Q
Brand: Banner
Price: 141 USD
Availability: BackOrder

Part#:K50BCLGA230Q

Manufacturer:Banner

Alt. Part#:30101

Product Lifecycle:Active

Get a quick Quote!

K50 Beacon EZ-LIGHT: 1-Color Perimeter & Top View; Voltage: 100-250 V ac; Housing: Polycarbonate; IP69K; Colors: Green; Micro-style Integral QD

About the manufacturer: Banner is one of the manufacturers that offers Pick-to-Light Sensors that you can order at Powermatic Associates site. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.

Check out the K50BCLGA230Q Banner price in the box on the right side or send a quick quote.

Product Details

Weight
113.398 g
Country Of Origin
MX
Pro-Editor Compatible (Discrete)
No
Wireless
No
Modbus RTU
No
IO Link
No
Feature: Quick Disconnect
Yes
Indication Intensity
High Brightness & Daylight Visible
Feature: Chemical Resistant
No
Feature: Audible
No
Multi-Color Device
Single Color On
Feature: Hazardous Area
No
Feature: Washdown Rated
Yes
Primary Window Material
Polycarbonate Clear
Min Op. Temperature (°C)
-40
Primary Housing Color
Black
Max Op. Relative Humidity Non-Condensing (%)
90% @ 50°C
Max Op. Temperature (°C)
50
Environmental Rating
IP67; IP69
NEMA Type and UL Type Rating
NEMA 4X, 13

Physical Dimensions (LxWxH or DxH mm)

50.0 x 60.0

Max Input Response Time (ms)

0.5

Input Type

Number of Input Pins/Conductors

Supply Voltage

100-250 V ac/90-240 V dc

Max Current Color (mA)

Connection

Integral QD

Animation Option 1

Solid On

Color Option 1

Green

Color Technology

Standard LED

Power Source

DC or AC

Power

DC or AC

Number of Colors / Segments

Product Size (mm)

Housing Style

Base Mount - Flat Window

Indication

Yes

Color Input Control

Individual (One wire/color, same number of colors as input wires)

Primary Housing Material

Polycarbonate

Mounting Thread

M30 x 1.5

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

K50BCLGA230Q Description

Banner Engineering K50BCLGA230Q is a high-intensity industrial LED light beacon from the EZ-LIGHT Beacons series. This beacon features perimeter and top view lighting with a 1-tier, 1-color green LED illumination housed in a black casing. The round flat window is made of clear polycarbonate (PC), and the base is also constructed from polycarbonate (PC), ensuring durability. It is pre-equipped with a 3-pin 1/2"-20UNF Micro-style QD connector for connectivity. The K50BCLGA230Q operates on a supply voltage range of 75Vdc-120Vdc (110Vdc nominal) for DC and 85Vac-130Vac (100Vac / 110Vac / 120Vac nominal) for AC. It offers versatile mounting options including surface, base pole M30, and 1/2" NPSM thread, with a cap diameter of 50mm / 2". Designed to function in ambient air temperatures ranging from -40°C to +50°C, it boasts a high degree of protection with ratings of IP67, IP69K, NEMA 4X, and NEMA 13. The current consumption is 60mA, and it features 1 x digital input (85-130Vac / 75-120Vdc) for color control.

$141.00

Request a quote, and we will send availability within minutes.

Select Qty:

$141.00

$141.00 each

Average response time: 11 minutes

Worldwide Shipping and Delivery

Secure Payment Processing

Warranty

Responsive Customer Support
