DELSEF-81D Banner Cordsets
Product Details
- Weight 40.82328 g
- Country Of Origin TW
- Oil/Grease Resistant No
- Feature: Hazardous Area No
- Secondary AWG 22
- Secondary Number of Conductors 8
- Secondary Orientation Straight
- Secondary Gender Female
- Secondary Coupling Method M12 Single Key
- Primary Number of Conductors 8
- Primary AWG 22
- Secondary Connector Type EURO
- Voltage Rating (V) 60 V ac/75 V dc
- IP Rating IP67
- Primary Connector Type LS-Custom
- Primary Gender Female
- Primary Orientation Straight
- Minimum Temp. (°C) -20
- Primary Coupling Method EZS-LS
- Maximum Temp. (°C) 55
- Current Rating (A) 2.0
- Coupling Material/Color Custom
- Connector Body Material/Color PVC Black
- Number of Connectors 2
- Trunk Length (m) No Trunk
- Outside Cable Diameter (mm) 6
- Shield/No Shield No Shield
- Number of Contacts 12
- Cordset Length (m) 0.3
- Cable Jacket Color Yellow
- Cable Jacket Material PVC
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of DELSEF-81D on Powermatic Associates is $57.00. Order now.
About the product
Banner Engineering DELSEF-81D is a pre-assembled cable/cordset designed with a double-ended configuration, featuring an 8-pin LS female connector and an 8-pin Euro-style M12 female connector. This part is constructed from nickel-plated brass coupling nuts and PVC cable, ensuring durability. It operates within an ambient air temperature range of -20 to +55°C and offers a degree of protection rated at IP67, making it suitable for various industrial environments. The cable has a diameter of 6mm and a length of 1ft (300mm), with yellow sheathing for visibility. It is rated for 60Vac and 75Vdc, accommodating a broad range of power supply requirements.
