Pilz PILZ-890165 is a protection unit designed for phase sequence monitoring relay applications. It features DIN rail mounting and operates within an ambient air temperature range of -15 to +55°C. The unit has a net height of 87 mm and utilizes fixed screw terminal connections for secure installation. It is designed to work with a supply voltage range of 400Vac-500Vac, specifically accommodating 415Vac, 440Vac, and 480Vac nominal values, within the S1PN sub-range. The dimensions include a width of 22.5mm and a depth of 121 mm, offering a compact form factor with an IP40 degree of protection. The housing is made from PPO material, ensuring durability. This model is suitable for 3-phase (3AC) input networks with a rated voltage of 400-500Vac. It has a power consumption of 8 VA and operates in a normally energized mode. For connectivity, it features 2 x auxiliary outputs (2CO changeover / 2xSPDT-NO/NC contacts) and 1 x analog input for L1-L3 voltage measurement. The protection functions include phase sequence and phase failure, ensuring the safety and proper operation of connected systems.

Pilz PILZ-890100 is a protection unit designed for true power monitoring with a relay function. It features nine different measuring ranges, adjustable switching for underload and overload thresholds, and customizable monitoring reaction and start-up suppression times. This unit is suitable for DIN rail mounting and has a net height of 87 mm. It supports a rated current of 18A for measuring and safety output contacts ratings ranging from 0.1A to 5A at 24Vdc (DC-1; 120W) and 0.1A to 1.5A at 24Vdc (DC-13). The connection is established via fixed screw terminal connections. As part of the S1WP sub-range, it measures 22.5mm in width, offers an IP40 degree of protection, and operates on a supply voltage of 20.4-30Vdc (24Vdc nominal). The frequency range for measurement extends up to 1kHz, and it is housed in a PPO material. It accommodates both single-phase (1AC) and three-phase (3AC) input types, with a rated voltage for AC measuring up to 240Vac/dc. The unit's width is 22.5 mm, depth is 121 mm, and it consumes 2W of power. It is designed to operate within an ambient air temperature range for storage of -40 to +85°C. The digital outputs include 1 x auxiliary output (SPDT-NO/NC contacts; 0.1-5A 24Vdc DC-1 120W resistive load), and the analog inputs comprise 1 x analog input for current measurement (K1-UL1) and 1 x analog input for voltage measurement (L1-L3). Protection functions include underpower and overpower monitoring, and it also features 1 x analog output for voltage (U) and current (I) monitoring.

Pilz PILZ-890070 is a protection unit designed for true power monitoring with a relay that supports 9 different measuring ranges. It features adjustable switching thresholds for underload and overload conditions, along with customizable monitoring reaction times and start-up suppression times. This unit is suitable for DIN rail mounting and operates within an ambient air temperature range of 0 to +55°C. It has a net height of 87 mm and is designed to measure from 0 percent, with a rated current of 9A for measuring current. The safety output contacts ratings are specified as 0.1A-5A for both 24Vdc (DC-1; 120W) and 240Vac (AC-1; 1200VA), and 0.1A-1.5A for 24Vdc (DC-13) as well as 0.1A-1.8A for 230Vac (AC-15). Connection is facilitated through fixed screw terminal connections. The supply voltage ranges from 27.5-264.5Vac for AC and 93.5-287.5Vdc for DC, with nominal values including 110Vac/120Vac/220Vac/230Vac for AC and 110Vdc/120Vdc/220Vdc/250Vdc for DC. The S1WP sub-range model has dimensions of W22.5mm and offers IP40 degree of protection. It operates within a frequency range of 0-1kHz for measuring, encased in a PPO housing. This unit is compatible with both single-phase (1AC) and 3-phase (3AC) input types of network, with a rated voltage of 0-415Vac/dc for measuring voltage. The net width is 22.5 mm, and it consumes 5 VA of power, with a net depth of 121 mm. It can be stored in ambient air temperatures ranging from -40 to +85°C. The digital outputs include 1 x auxiliary output (SPDT-NO/NC contacts; 0.1-5A 24Vdc 120W DC-1 or 240Vac 1200VA AC-1 resistive load), and the analog inputs comprise 1 x analog input for current measurement (K1-UL1) and 1 x analog input for voltage measurement (L1-L3). Its protection functions include underpower and overpower, with 1 x analog output for voltage-U and current-I measurements.

Pilz PILZ-890060 is a protection unit designed for true power monitoring with a relay that supports 9 different measuring ranges. It features adjustable switching for underload and overload thresholds, along with customizable monitoring reaction time and start-up suppression time. This unit is suitable for DIN rail mounting and operates within an ambient air temperature range of 0 to +55°C. It has a net height of 87 mm and is capable of handling a rated current of 9A for measuring, with safety output contacts ratings ranging from 0.1A to 5A at 24Vdc (DC-1; 120W) and 240Vac (AC-1; 1200VA), and lower ratings for DC-13 and AC-15 applications. The connection type is fixed screw terminals, and it accepts a supply voltage of 27.5-264.5Vac for various nominal voltages, as well as a DC supply voltage range of 93.5-287.5Vdc. The unit operates within a frequency range of 0-1kHz for measuring, is housed in PPO material, and can be used with both single-phase and 3-phase input networks. The rated voltage for measuring is up to 550Vac/dc, with a net width of 22.5 mm and a depth of 121 mm. It has a power consumption of 5 VA, an IP40 degree of protection, and is designed for storage in temperatures ranging from -40 to +85°C. The unit includes 1 x auxiliary output (SPDT-NO/NC contacts) for resistive loads, 1 x analog input for current measurement, 1 x analog input for voltage measurement, and 1 x analog output for voltage and current signaling, with underpower and overpower protection functions.

Pilz PILZ-890000 is an insulation monitor designed for DIN rail mounting, featuring insulation monitoring relay, insulation monitoring, earth fault monitoring, and a test mode. It operates within an ambient air temperature range of -10 to +55°C and has a net height of 87 mm. The device supports rated current safety output contacts ratings from 0.1A to 5A for both 24Vdc (DC-1; 120W) and 240Vac (AC-1; 1200VA), along with 1.5A for 24Vdc (DC-13) and 2A for 230Vac (AC-15). Connection is established via fixed screw terminal connections. The supply voltage ranges from 24Vac to 240Vac (with nominal voltages of 110Vac, 220Vac, 230Vac) and from 24Vdc to 240Vdc (with nominal voltages of 110Vdc, 120Vdc, 220Vdc). It belongs to the S1EN sub-range, measures 22.5mm in width, and offers a degree of protection of IP40. The housing is made of PPO material, and it can handle rated voltages up to 400Vac. The net width is 22.5 mm, and it consumes 1 W of power, with a net depth of 121 mm. Operating modes include automatic reset/manual reset and normally energized mode. It can be stored in temperatures ranging from -40 to +85°C. The device includes 1 x auxiliary output (SPDT-NO/NC contacts; 0.1-5A 24Vdc 120W DC-1 or 240Vac 1200VA AC-1 resistive load), protection functions against overcurrent, and digital inputs for main voltage (42-240Vac and 24Vdc) and a reset input.

Pilz PILZ-840765 is a protection unit designed for thermistor monitoring relay thermistor monitoring with a DIN rail mounting mode. It operates within an ambient air temperature range of -10 to +55°C and features a net height of 87 mm. This unit is equipped with an automatic reset design and fixed screw terminal connections. It supports a supply voltage of 20.4-26.4Vac (24Vac nominal) and 20.4-26.4Vdc (24Vdc nominal), falling under the S1MS sub-range. The dimensions include a width of 22.5mm and a degree of protection rated at IP40, with a PPO housing material. The net width is 22.5 mm, and it has a power consumption of 2 W, with a net depth of 121 mm. Its operating mode is an automatic reset in a normally energized mode. The digital outputs consist of 2 x auxiliary outputs (2CO changeover / 2xSPDT-NO/NC contacts) (12-14-11; 22-24-21), and it also features 2 x analog inputs (T1-T2 measuring circuits). The protection functions include overheating protection (Thermistor).

Pilz PILZ-840420 is a protection unit designed for thermistor monitoring relay thermistor monitoring with a manual reset design. It features DIN rail mounting and operates within an ambient air temperature range of -10 to +55 °C. The unit has a net height of 87 mm and is equipped with fixed screw terminal connections. It supports a supply voltage of 20.4-26.4Vac (24Vac nominal) and 20.4-26.4Vdc (24Vdc nominal), falling under the S1MO sub-range. The dimensions include a width of 22.5 mm and a depth of 121 mm, with a degree of protection rated at IP40. Constructed with a PPO housing, it has a net width of 22.5 mm and consumes 2 W of power. The operating mode is manual reset in a normally energized mode. It can be stored in temperatures ranging from -40 to +85 °C. The unit features 2 x auxiliary outputs (2CO changeover / 2xSPDT-NO/NC contacts) for digital outputs, 2 x analog inputs (T1-T2 measuring circuits), and 2 x reset circuit inputs (X2-X1) for digital inputs. Its protection functions include overheating protection through thermistor monitoring.

Pilz PILZ-840630 is a protection unit designed for thermistor monitoring relay applications, featuring thermistor monitoring as its main function. It is suitable for DIN rail mounting and operates within an ambient air temperature range of -10 to +55 °C. This unit has a net height of 87 mm and incorporates a manual reset design with fixed screw terminal connections. It requires a supply voltage of 204-264Vac (240Vac nominal) and falls under the S1MO sub-range. The dimensions include a width of 22.5mm and a depth of 121 mm, offering a degree of protection of IP40. The housing is made of PPO material, ensuring durability. With a power consumption of 3.5 VA, this unit operates in a normally energized mode with manual reset functionality. It can withstand an ambient air temperature for storage between -40 and +85 °C. The PILZ-840630 features 2 x auxiliary outputs (2CO changeover / 2xSPDT-NO/NC contacts) for digital outputs, 2 x analog inputs (T1-T2 measuring circuits) for monitoring, and is equipped with 2 x reset circuit inputs (X2-X1) for digital inputs. Its protection functions are specifically designed for overheating protection, utilizing thermistors to safeguard against temperature-related issues.

Pilz PILZ-840620 is a protection unit designed for thermistor monitoring relay applications, featuring thermistor monitoring as its main function. It is engineered for DIN rail mounting and operates within an ambient air temperature range of -10 to +55°C. This unit has a net height of 87 mm, incorporates a manual reset design, and utilizes fixed screw terminal connections for secure installation. It is supplied with a voltage range of 195.5-253Vac (230Vac nominal) under the sub-range name S1MO. The dimensions include a width of 22.5mm and a depth of 121 mm, offering a compact form factor with an IP40 degree of protection. The housing is made from PPO material, ensuring durability. Power consumption is rated at 3.5 VA. The operating mode is manual reset in a normally energized configuration. For storage, it can withstand ambient air temperatures from -40 to +85°C. It features 2 x auxiliary outputs (2CO changeover / 2xSPDT-NO/NC contacts) for digital outputs and 2 x analog inputs (T1-T2 measuring circuits) for monitoring. Additionally, it includes 2 x reset circuit inputs (X2-X1) for digital inputs and offers overheating protection through its thermistor protection function.

Pilz PILZ-837395 is a protection unit designed for voltage monitoring with a threshold value element for controllers. It features DIN rail mounting and operates within an ambient air temperature range of -10 to +55°C. The unit has fixed screw terminal connections and supports a supply voltage range of 20.4-264Vac, including 24Vac, 110Vac, 120Vac, 230Vac, and 240Vac, as well as a DC supply voltage of 20.4-26.4Vdc with a nominal 24Vdc. The S1UK sub-range model comes with dimensions of 22.5mm in width, 87mm in height, and 121mm in depth, and offers an IP40 degree of protection. The frequency measuring range is 0.4-400Hz, and the housing is made of PPO material. It has a rated voltage of 1Vac/dc for measuring voltage. The operating mode includes fault non-latching and normally de-energized mode, with digital outputs featuring 1 x auxiliary output (SPDT-NO/NC contacts) and analog inputs including 1 x analog input for U-V voltage measurement. The protection functions include overvoltage protection.
