Anybus by HMS Networks AB7861-F is a gateway belonging to the X-gateway series designed to function as a protocol translator between DeviceNet and Modbus Plus networks. It supports installation in both vertical and flat orientations and features galvanic isolation on both the BUS and Ethernet sides. Configuration of the I/O is facilitated via a USB port using the Anybus Configuration Manager software. The design incorporates a DeviceNet adapter and Modbus Plus slave functionality, equipped with 8 configuration switches, 10 LED indicators for fieldbus, sub-network, and device status, along with 6 node ID and 6 source ID switches. The device requires a supply voltage ranging from 19.2 to 28.8Vdc, with a nominal voltage of 24Vdc, and has dimensions of H127mm x W44mm x D114mm. Its housing is made from aluminium and plastic, ensuring durability and resilience. Connection interfaces include a 5-pin plug-in connector for DeviceNet, a 9-pin D-sub female connector for Modbus Plus, a 2-poles 5.08mm plug-in screw connector for power, and a USB connector for configuration. It offers an IP20 and NEMA 1 degree of protection and is designed for DIN rail mounting. The AB7861-F supports DeviceNet and Modbus Plus communication protocols and operates within an ambient air temperature range of -25 to +65 °C. It has a current consumption of 400mA at maximum and 200mA typically. The device is capable of operating in environments with 5-95% relative humidity (non-condensing) and can be stored in temperatures ranging from -40 to +85 °C. Communication speeds are 125kbit/s, 250kbit/s, and 500kbit/s for DeviceNet, and 1Mbit/s for Modbus Plus.

HMS eWon component

HMS eWon component

Ixxat by HMS Networks 1.04.0075.02000 is a CAN termination connector designed for automation applications. It features a 1 x 9-pin D-sub male connector for plug-in connections and is rated for a current of 3A. The connector is designed with an integrated 120Ω resistance for CAN termination, supporting Normally Open (NO) auxiliary contacts. It operates effectively within an ambient air temperature range of -55 to +105°C. The connector's contacts are made of brass with gold plating over nickel, and the shell is tin plated. This part also includes accessories with a visual position indicator.

Ixxat by HMS Networks 1.04.0085.00001 is an external antenna designed for use with CANblue II accessories. It features a vertical polarization and a VSWR of 1.5 to 1 max at resonance, ensuring optimal performance. The antenna is equipped with a 1 x RP-SMA male polarized connector for easy connection. It boasts a 1dBi gain and is rated for a power of 5W. The antenna operates effectively within an ambient air temperature range of -40 to +80°C and has an impedance of 50 Ω. With dimensions of 97.15mm in height and a diameter of 10.5mm, this accessory is designed to withstand a drop test of 1M, highlighting its durability.

HMS eWon component

HMS eWon component

HMS eWon component

Anybus by HMS Networks AB7012-B is a gateway designed for serial communication, belonging to the Serial Communicators sub-range. This gateway supports configurable RS-232/422/485 protocols for produce/consume and query/response ASCII operations, accommodating up to 31 stations with RS485/422 and offering a baud rate range of 1.2-57.6kbit/s. It adheres to physical standards of RS232/422/485 and supports various Modbus commands including Read Coils, Read Discrete Inputs, and Write Multiple Registers, among others. Additionally, it provides DF1 services such as Integrity Check and Read Diagnostics. The AB7012-B features reverse voltage protection, short circuit protection, and galvanic isolation on the sub-network, with an MTTF of over 550,000 hours. It is designed for installation at altitudes up to 2000m and offers immunity and emission protection suitable for industrial environments. The design includes 6 LED indicators, a baud rate jumper, and is powered by a supply voltage of 21.6-26.4Vdc. Its dimensions are H120mm x W27mm x D75mm, housed in ABS/PC plastic, and it connects via a 9-pin D-sub and a 2-poles plug-in connector, among others. The AB7012-B is IP20 and NEMA 1 rated, mounts on a DIN rail, and operates within an ambient air temperature of 0 to +55°C, with a current consumption of 300mA (max) and 100mA (typical). It is designed for use with INTERBUS, RS-232, RS-422, and RS-485 communication protocols, and can operate in environments with up to 95% non-condensing relative humidity.

Anybus by HMS Networks AB7849-F is a gateway within the X-gateway series designed for protocol translation. It functions as both a PROFIBUS slave and a CANopen slave. This gateway allows for vertical or flat installation and features galvanic isolation on both the BUS and Ethernet sides. Configuration of I/O is facilitated via a USB port using the Anybus Configuration Manager software. The device includes 4 node address switches (x10 / x1), a baud rate switch, and 10 LED indicators for fieldbus, sub-network, and device status monitoring. It operates on a supply voltage of 19.2-28.8Vdc (24Vdc nominal) and has dimensions of H127mm x W44mm x D114mm. The housing is made from aluminium and plastic, ensuring durability. Connection interfaces include a 9-pin D-sub female connector for PROFIBUS, a 9-pin D-sub male connector for CANopen, a 2-poles 5.08mm plug-in screw connector for power (X3), and a USB connector (X4) for configuration. It offers an IP20 and NEMA 1 degree of protection and is designed for DIN rail mounting. The AB7849-F supports communication protocols of CANopen and PROFIBUS, operates within an ambient air temperature range of -25...+65°C for operation and -40...+85°C for storage. It has a current consumption of 400mA (24Vdc; max.) and 200mA (typical), with a speed of up to 12Mbit/s for PROFIBUS and 10kbit/s to 1Mbit/s for CANopen slave. The device is designed to operate in environments with 5-95% relative humidity (RH; non-condensing).
