723-612 WAGO Electrical Connector Accessories

723-612 on Powermatic Associates
WAGO

Part#:723-612

Manufacturer:WAGO

Category:Electrical Connector Accessories

Product Lifecycle:Active

Product description

723-612 WAGO - 1-conductor male connector; CAGE CLAMP®; 2.5 mm²; Pin spacing 7.5 mm; 12-pole; 100% protected against mismating; 2,50 mm²; light gray

Product Details

  • Weight
    22.24000585 g
  • Country Of Origin
    Germany
  • HTS Code
    85366990990
  • Weight
    22.240 grams
  • Width
    3.571 inches, 90.7 millimeters
  • Voltage
    300 volts, 500 volts
  • Strip Length
    0.35 inches, 9 millimeters
  • Package Type
    Box
  • Insulation Material
    Polyamide
  • Flammability Class
    V0
  • Depth
    1.083 inches, 27.5 millimeters
  • Height
    0.563 inches, 14.3 millimeters
  • Country of Origin
    Germany
  • Current
    12 amperes, 15 amperes
  • Contact Type
    Tin
  • Contact Material
    Copper
  • Connection Type
    For Conductor
  • Conductor Size
    12 american wire gauge, 2.5 millimeters
  • Color
    Gray
  • Actuator
    Operating Tool

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 723-612 on Powermatic Associates is $12.34. Order now.


About the product

WAGO 723-612 is a connector part of the MCS - MULTI CONNECTION SYSTEM, designed without breaking capacity as specified in DIN EN 61984, indicating it should not be connected or disconnected under load or when live. It adheres to IEC/EN 60664-1 standards, with nominal voltages of 500V (III/3), 630V (III/2), and 1000V (II/2), all with a rated impulse voltage of 6kV and a rated current of 12A. UL and CSA approvals include ratings of 300V and 600V with currents ranging from 10A to 15A, depending on the use group. It features 12 connection points, a single connection type with CAGE CLAMP technology, and supports solid and fine-stranded conductors of various sizes. The connector has a pin spacing of 7.5mm, dimensions of 90.7mm in width, 14.3mm in height, and 27.5mm in depth, and includes features like variable coding, anti-rotation protection, and mismating protection. The material composition includes a light gray Polyamide (PA66) insulation, Chrome-Nickel spring steel for the clamping spring, and tin-plated Electrolytic Copper contacts. It operates within a temperature range of -60 to +100°C, is RoHS compliant, and comes in a box of 25 pieces with the country of origin being Germany.


Manufacturer warranty
