704-5013 WAGO I/O Connectors

704-5013 on Powermatic Associates
WAGO

Part#:704-5013

Manufacturer:WAGO

Category:I/O Connectors

Product Lifecycle:Active

Product description

704-5013 WAGO - Interface module for system wiring; Pluggable connector per DIN 41651; Male connector; 10-pole; 8-channel relay output; 1 changeover contact; Triple-deck PCB terminal blocks; with manual operation; in mounting carrier; 2,50 mm²

Product Details

  • Weight
    240.0000631 g
  • Country Of Origin
    France
  • HTS Code
    85364900990
  • Width
    2.953 inches, 75 millimeters
  • Weight
    240.000 grams
  • Package Type
    Box
  • Mounting Type
    DIN-35 Rail
  • Height
    105 millimeters, 4.134 inches
  • Contact Material
    AgSnO2
  • At Rated Voltage
    50 volts

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 704-5013 on Powermatic Associates is $871.00. Order now.

About the product

Wago 704-5013 is an interface unit designed for relay outputs interface module applications. It operates on a supply voltage of 21.6-26.4Vdc with a nominal 24Vdc and does not specify an AC supply voltage. This unit features a DIN 41651 10-pin male connector for system connections, a triple-deck spring cage-clamp with 24 pins for 0.08...2.5mm2 cables in the field, and a spring cage-clamp 4-pin for 0.08...2.5mm2 cables for supply connections. It is designed for manual operation within a mounting carrier. The ambient air temperature for operation ranges from C to +40°C, with a storage temperature tolerance from C to +70°C. The rated insulation voltage (Ui) is specified at 70mm, and it has a net depth for 10-poles (10P). The unit is designed for mounting on a DIN-35 rail vertically and measures H105mm x W75mm x D65mm. Connection capacity is facilitated by Silver-Tin (AgSnO) contacts, and it features an 8-channel output with 8 x digital outputs (C/O / SPDT (Single Pole Double Throw) relay contact type, supporting up to 250Vac / 48Vdc for protected poles. The coating material is designed to withstand 85% relative humidity (RH, non-condensing).

Manufacturer warranty

704-5013 WAGO

$871.00

Your price can be lower.
Log in or Create account to check your discount

Select Qty:

$871.00

$871.00 each

Average response time: 11 minutes

Worldwide Shipping and Delivery

Secure Payment Processing

Warranty

Responsive Customer Support

Got Questions? We've Got Answers!

Need more details?

Feel free to chat with us
