2636-1357 WAGO Industrial Automation Components

2636-1357 on Powermatic Associates
WAGO

Part#:2636-1357

Manufacturer:WAGO

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

2636-1357 WAGO - PCB terminal block; Pin spacing 15 mm; double pinning; 7-pole; Push-in CAGE CLAMP®; gray

Product Details

  • Weight
    68.34801798 g
  • Country Of Origin
    Germany
  • HTS Code
    85369010000
  • Width
    101.6 millimeters, 4.000 inches
  • Weight
    72.368 grams
  • Voltage
    1000 volts, 300 volts
  • Package Type
    Box
  • Operating Temperature
    105 degrees celsius
  • Mounting Type
    Feed-through Mounting
  • Strip Length
    0.79 inches, 20 millimeters
  • Insulation Material
    Polyamide
  • Height
    1.283 inches, 32.6 millimeters
  • Flammability Class
    V0
  • Depth
    1.146 inches, 29.1 millimeters
  • Current
    76 amperes, 85 amperes
  • Country of Origin
    Poland
  • Conductor Size
    16 millimeters, 4 american wire gauge
  • Contact Type
    Tin
  • Contact Material
    Copper
  • Actuator
    Operating Tool
  • Color
    Gray

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 2636-1357 on Powermatic Associates is $23.49. Order now.

About the product

WAGO 2636-1357 is an automation part with a short circuit breaking rating and electrical data ratings per IEC/EN 60664-1, including a nominal voltage (III/3) of 1000V, rated impulse voltage (III/3) of 8kV, rated voltage (III/2) of 1000V, rated impulse voltage (III/2) of 8kV, nominal voltage (II/2) of 1000V, rated surge voltage (II/2) of 8kV, and a rated current of 76A. It has UL 1059 approvals with rated voltages of 300V for Use Group B and C, and 600V for Use Group D, with respective rated currents of 85A for Groups B and C, and 5A for Group D. CSA approvals include rated voltages of 300V for Use Groups B and C, and 600V for Use Group D, with a rated current of 66A for all groups. The part features 7 connection points, a single connection type with push-in CAGE CLAMP technology, and supports solid and fine-stranded conductors ranging from 0.75 to 25mm2. It has a pin spacing of 15mm, dimensions of 101.6mm in width, 32.6mm in height, and 29.1mm in depth, with a feed-through mounting type. The terminal is made from Polyamide (PA66) with a flammability class of V0, and chrome-nickel spring steel for the clamping spring. It operates within a temperature range of -60 to +105°C, is RoHS compliant, and comes in a box of 20 pieces with the country of origin being Poland.
