2061-904/034-000 WAGO Industrial Automation Components

2061-904/034-000 on Powermatic Associates
WAGO

Part#:2061-904/034-000

Manufacturer:WAGO

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

2061-904/034-000 WAGO - Board-to-Board Link; Pin spacing 6 mm; 4-pole; Length: 34 mm; white

Product Details

  • Weight
    1.420000373 g
  • Country Of Origin
    China
  • HTS Code
    85369010000
  • Width
    0.933 inches, 23.7 millimeters
  • Weight
    1.420 grams
  • Voltage
    250 volts
  • Package Type
    Box
  • Insulation Material
    Polyamide
  • Height
    0.098 inches, 2.5 millimeters
  • Flammability Class
    V0
  • Depth
    1.339 inches, 34 millimeters
  • Current
    9 amperes
  • Country of Origin
    China
  • Contact Type
    Silver
  • Contact Material
    Copper Alloy
  • Color
    White

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 2061-904/034-000 on Powermatic Associates is $0.95. Order now.

About the product

WAGO 2061-904/034-000 is an SMD PCB terminal block designed for a maximum of 10 mating cycles, suitable for 2061 Series applications. It features a nominal voltage of 250V (III/3), 320V (III/2), and 630V (II/2) with a rated current of 9A and a rated impulse voltage of 4kV across all categories. The terminal block has a total of 4 potentials with a 4-pole connection and a pin spacing of 6mm. Its dimensions are 23.7mm in width, 2.5mm in height, and 34mm in depth. Constructed from white polyamide (PA66) with a flammability class of V0, it uses a copper alloy for the contact material with a silver plating. The part weighs 1.4g and operates within a temperature range of -60 to +105°C. It is RoHS compliant without exemptions, packaged in boxes of 100 pieces, and has a GTIN of 4055143656757. The country of origin is CN, and it has a customs tariff number of 85369010000.
