WFS 4.4-PCB Turck Panel-Mount Receptacles

Turck WFS 4.4-PCB WFS 4.4-PCB Actuator and Sensor Receptacle, Rear Mount
Turck

Part#:WFS 4.4-PCB

Manufacturer:Turck

Alt. Part#:U2369-2

Product Lifecycle:Active

In-stock parts: 44

Oct 19, 2024

WFS 4.4-PCB Actuator and Sensor Receptacle, Rear Mount

About the manufacturer: Turck is one of the manufacturers that offers Panel-Mount Receptacles that you can order at Powermatic Associates site. Turck is a leading provider of sensor, fieldbus, and connectivity technologies, along with interface technology, human-machine interfaces (HMI), and RFID systems. We offer innovative solutions for factory and process automation requirements, guaranteeing top-notch performance.

Check out the WFS 4.4-PCB Turck price in the box on the right side or send a quick quote.

Product Details

  • RoHS
    Yes
  • Country Of Origin
    MEX
  • HTS Code
    8536694020
  • Approvals
    RoHS
  • Current
    4 A
  • Voltage
    250 V
  • Connector A - Number of Pins
    4
  • Mounting Thread A
    M12 × 1
  • Connector A
    M12
  • Material coupling/housing A
    Brass
  • Connector A - Style
    Male Receptacle
  • Application
    Actuator and Sensor

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

WFS 4.4-PCB Description

Turck WFS 4.4-PCB is a connector (receptacle) featuring a nickel-plated brass housing with a PVC jacket. It is designed with a right-angled 4-pin M12 eurofast male receptacle and includes Pg9 panel-mounting thread for secure installation. The connector also has 4-pin PCB pins for direct board connections. It is rated for a current of 4A and a voltage of 250Vac. This part functions primarily as a panel-mount receptacle bulkhead connector.

Related documents WFS 4.4-PCB Specs

WFS 4.4-PCB WFS 4.4-PCB.pdf
