M9F53206 Schneider Electric Industrial Automation Components

Name: M9F53206
Brand: Schneider Electric
Price: 169.19 USD
Availability: InStock

Part#:M9F53206

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

In-stock parts: 3

Dec 21, 2024

Schneider Electric M9F53206 is a Miniature Circuit Breaker (MCB) within the C60BPR sub-range, designed with a 2 Pole configuration and a rated current of 6A. It features a rated insulation voltage (Ui) of 500 V and a rated impulse voltage (Uimp) of 6 kV. This MCB offers a short circuit breaking rating of 14kA AIR at both 120Vac and 240Vac, and 10kA AIR at 480Y/277Vac and 125Vdc. It supports a rated voltage (AC) for phase-to-phase connections up to 440 V and ensures both poles are protected. The tripping curve for this device is classified as D.

About the manufacturer: Schneider Electric is one of the manufacturers that offers Industrial Automation Components that you can order at Powermatic Associates site. We provide digital solutions for energy and automation that improve efficiency and support sustainability. Our comprehensive solutions include cutting-edge energy technologies, real-time automation, software, and services for residential, commercial, and industrial settings.

Check out the M9F53206 Schneider Electric price in the box on the right side or send a quick quote.

Product Details

[Ics] Rated Service Breaking Capacity
4.5 kA 75 % GB 14048.2 - 240 V AC 7.5 kA 75 % GB 14048.2 15 kA 75 % GB 14048.2 4.5 kA 75 % EN/IEC 60947-2 - 125 V DC 7.5 kA 75 % EN/IEC 60947-2 - 440 V AC 15 kA 75 % EN/IEC 60947-2 - 415 V AC
Standards
EN/IEC 60947-2 GB 14048.2 UL 489 CSA C22.2 No 5
Product Certifications
IEC CCC CSA UL
[Ue] Rated Operational Voltage
240 V AC 50/60 Hz 415 V AC 50/60 Hz 440 V AC 50/60 Hz
Network Type
DC AC
Magnetic Tripping Limit
12 x In +/- 20 % AC 17 x In +/- 20 % DC
Breaking Capacity
6 kA Icu 440 V AC EN/IEC 60947-2 10 kA Icu 415 V AC EN/IEC 60947-2 20 kA Icu 240 V AC EN/IEC 60947-2 6 kA Icu 440 V AC GB 14048.2 10 kA Icu 415 V AC GB 14048.2 20 kA Icu 240 V AC GB 14048.2 14 kA AIR 240 V AC UL 489 10 k
Tightening Torque
17.70 lbf.in (2 N.m) top or bottom
Connections - Terminals
Ring terminal top or bottom)
Earth-Leakage Protection
Without
Provision For Padlocking
Padlockable
Electrical Durability
10000 cycles
Mechanical Durability
20000 cycles
Color
Gray
9 Mm Pitches
4
Depth
2.83 in (72 mm)
Mounting Support
DIN rail
Mounting Mode
Clip-on
Local Signalling
ON/OFF indication
Control Type
Toggle

Width

1.42 in (36 mm)

Contact Position Indicator

Yes

[Uimp] Rated Impulse Withstand Voltage

6 kVEN/IEC 60947-2

Height

5.00 in (127 mm)

[Ui] Rated Insulation Voltage

500 V AC EN/IEC 60947-2

Trip Unit Technology

Thermal-magnetic

Suitability For Isolation

Yes EN/IEC 60947-2

Curve Code

Line Rated Current

6 A 77 °F (25 °C) EN/IEC 60947-2

Number Of Protected Poles

Device Application

Distribution

Device Short Name

C60BPR

Range

Multi 9

Product Or Component Type

Miniature circuit-breaker

Product Name

Multi 9 C60

Poles Description

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
