LRD05L6 Schneider Electric Thermal Overload Relays

LRD05L6 on Powermatic Associates
Schneider Electric

Part#:LRD05L6

Manufacturer:Schneider Electric

Category:Thermal Overload Relays

Product Lifecycle:Active

Get a quick Quote!

Schneider Electric LRD05L6 is a differential thermal overload relay designed for direct connection to a contactor and features screw-clamp terminals for the control circuit. This 3-pole device offers protection functions classified under Class 20, with a rated current range of 0.63-1 A. It includes protection settings for thermal overload within the same current range. The LRD05L6 is equipped with 1 Normally Open (NO) and 1 Normally Closed (NC) auxiliary contacts, supporting a rated voltage (AC) phase-to-phase of up to 690 V at frequencies from 0 to 400Hz. The minimum and maximum current specifications are set at 0.63 A and 1 A, respectively.

About the manufacturer: Schneider Electric is one of the manufacturers that offers Thermal Overload Relays that you can order at Powermatic Associates site. We provide digital solutions for energy and automation that improve efficiency and support sustainability. Our comprehensive solutions include cutting-edge energy technologies, real-time automation, software, and services for residential, commercial, and industrial settings.

Check out the LRD05L6 Schneider Electric price in the box on the right side or send a quick quote.

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

LRD05L6 Description

Schneider Electric LRD05L6 is a differential thermal overload relay designed for direct connection to a contactor and features screw-clamp terminals for the control circuit. This 3-pole device offers protection functions classified under Class 20, with a rated current range of 0.63-1 A. It includes protection settings for thermal overload within the same current range. The LRD05L6 is equipped with 1 Normally Open (NO) and 1 Normally Closed (NC) auxiliary contacts, supporting a rated voltage (AC) phase-to-phase of up to 690 V at frequencies from 0 to 400Hz. The minimum and maximum current specifications are set at 0.63 A and 1 A, respectively.
