LR9D5367 Schneider Electric Industrial Automation Components

Product Details

• Connections - Terminals
  Power circuit bars Control circuit screw clamp terminals 1 0.00…0.00 in² (0.5…1.5 mm²) flexible without cable end Control circuit screw clamp terminals 2 0.00…0.00 in² (0.5…1.5 mm²) flexible without cable end Alarm circuit screw clamp termi
• Tightening Torque
  Alarm circuit 3.98 lbf.in (0.45 N.m) screw clamp terminals Power circuit 159.31 lbf.in (18 N.m) bars M8 Control circuit 10.62 lbf.in (1.2 N.m) screw clamp terminals
• [Ui] Rated Insulation Voltage
  Power circuit 1000 V IEC 60947-4-1 Power circuit 600 V CSA Power circuit 600 V UL
• Product Compatibility
  LC1D115 LC1D150 NSX circuit breaker
• Tripping Threshold
  1.05 +/- 0.06 In alarm IEC 60947-4-1 1.12 +/- 0.06 In de-energisation IEC 60947-4-1
• Mounting Support
  Under contactor Rail
• Control Type
  Red push-button stop Blue push-button reset
• Associated Fuse Rating
  4 A gG signalling circuit 4 A BS signalling circuit
• Net Weight
  1.95 lb(US) (0.885 kg)
• Depth
  4.92 in (125 mm)
• Width
  4.53 in (115 mm)
• Height
  4.65 in (118 mm)
• Switching Capacity In Ma
  0...150 mA
• Maximum Voltage Drop
  <2.5 V closed state
• Phase Failure Sensitivity
  Tripping in 4 s +/- 20 % IEC 60947-4-1
• [Uimp] Rated Impulse Withstand Voltage
  6 kV IEC 60947-1
• Temperature Compensation
  -4…140 °F (-20…60 °C)
• [Ue] Rated Operational Voltage
  690 V AC 0...400 Hz power circuit IEC 60947-4-1
• [Ith] Conventional Free Air Thermal Current
  5 A signalling circuit
• Auxiliary Contact Composition
  1 NO + 1 NC
Supply Voltage Limits
17…32 V
Network Frequency
50-60 Hz
[Us] Rated Supply Voltage
24 V DC
Thermal Protection Adjustment Range
60…100 A
Range
TeSys
Thermal Overload Class
Class 10 IEC 60947-4-1
Relay Application
Motor protection
Signalling Function
Alarm
Network Type
AC
Product Or Component Type
Electronic thermal overload relay
Device Short Name
LR9D
Product Name
TeSys LRD
