Part#:EDB36060SA

Manufacturer:Schneider Electric

Category:Electronic Components

Product Lifecycle:Active

Product description

E-Frame Branch Brkr 60A, 3P, 600Y/347V, 14kA, Bolt-on Mnt, Shunt Trip

Product Details

  • AWG Gauge
    AWG 12...AWG 2/0 aluminium AWG 14...AWG 2/0 copper
  • Protection Type
    Overload Short-circuit
  • Net Weight
    4 lb(US) (1.81 kg)
  • Depth
    4.05 in (102.87 mm)
  • Width
    3.92 in (99.57 mm)
  • Height
    5.66 in (143.76 mm)
  • Breaking Capacity Code
    D
  • Trip Unit Technology
    Thermal-magnetic
  • Device Composition
    Shunt trip
  • Product Destination
    NF panelboard
  • Number Of Spaces Required
    4
  • Number Of Spaces
    4
  • Number Of Poles
    3
  • Mounting Mode
    Bolt-on
  • Local Signalling
    Trip indicator
  • Holding Current
    630 A
  • Electrical Connection
    Lugs aluminium
  • Circuit Breaker Application
    HACR rated
  • Range Of Product
    125 A Frame EDB-EGB-EJB
  • Product Or Component Type
    Circuit-breaker
  • Device Short Name
    EDB
  • Breaking Capacity
    14 kA 600Y/347 V AC
  • Module Type
    E-Frame
  • Maximum Operating Voltage
    600Y/347 V AC
  • Line Rated Current
    60 A
  • Trip Unit Rating
    1800 A

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of EDB36060SA on Powermatic Associates is $1,424.00. Order now.
