16474621 SAB Ethernet Cables

Name: 16474621
Brand: SAB

Part#:16474621

Manufacturer:SAB

Category:Ethernet Cables

Product Lifecycle:Active

Get a quick Quote!

CATLine CAT 6A BL - 24 AWG/4pr, shielded halogen-free CAT 6A ethernet cable for Shipboard applications, UL, ABS, CE, RoHS

About the manufacturer: SAB is one of the manufacturers that offers Ethernet Cables that you can order at Powermatic Associates site. SAB North America acts as the central hub for sales, distribution, and service for SAB Bröckskes, a German company that specializes in cables, wires, cable harnesses, and temperature measurement tools. Our top-quality cables are shipped to more than 40 countries on a daily basis.

Check out the 16474621 SAB price in the box on the right side or send a quick quote.

Product Details

Color
Black
Weight
19.51 g
Chemical Resistant
NO
Oil Resistant
No
UV Resistant
NO
Halogen Free
YES
Submersible
NO
Direct Burial
NO
Movement Type
Stationary/Flexible
Application
Data
Gauge
24 AWG
Pair count
4
Number of conductors
8
Cable configuration
24 AWG (7 strand)/4pr
Stranding type
bare copper, fine strands
Insulation type
Special Polymer
Shielded
Yes
Voltage
90
Approvals
UR AWM, ABS, CE, EAC, RoHS
RoHS
YES

Temperature range

-40°C to +75°C

Outside diameter (OD)

0.287 in

UOM

CSA Certification

UL Certification

YES

CE Certification

YES

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

16474621 Description

SAB 16474621 Ethernet Cable is part of CATLine CAT 6A BL product family, and is designed for Data applications. This cable is 24 AWG with 8 conductors, and shielded 24 AWG (7 strand)/4pr cable configuration. Featuring Black color jacket, Special Polymer insulation, and bare copper, fine strands stranding. It has 0.287 in OD, constructed to support Stationary/Flexible movement type, and rated for 90 volts. This Data cable can operate in -40°C to +75°C temperature range, it is Halogen free, and has following approvals: UR AWM, ABS, CE, EAC, RoHS. This cable is an excellent choice for Data applications.
