PISA11.203206 Puls Protection Modules (DC)

PISA11.203206 on Powermatic Associates
Puls

Part#:PISA11.203206

Manufacturer:Puls

Category:Protection Modules (DC)

Product Lifecycle:Active

Product description

PULS PISA11.203206 is a protection unit designed as a 4-channel protection module with 1 input and 4 outputs, suitable for DIN rail mounting. It operates within an ambient air temperature range of -25 to +70°C and adheres to NEC Class 2 design specifications. The rated current for the device is 4A, distributed as 1A across each of the four outputs, and it features screw-clamp connections for secure installation. This part falls under the PISA11-series and has dimensions of W45mm x H75mm x D91mm. It requires a supply voltage of 18Vdc to 30Vdc, with 24Vdc as the typical value and 21.4Vdc as the necessary input voltage to activate the outputs. The output voltage is adjustable between 24Vdc and 28Vdc. Protection functions include short-circuit protection with a 110ms shutdown time and current limitation with a 9A to 12.7A adjustable threshold. Power dissipation at full output load with a 24V input is 1W, and the processing time for output turn-on delay is 270ms. The voltage drop across the device is 41mV / 0.041 V. Electrical durability is rated at 243,000 hours at 40°C with 4x0.5A output and 686,000 hours at 25°C with 4x0.5A output.

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

Similar products from: Puls Protection Modules (DC)

PISA11.402 on Powermatic Associates

PISA11.402

Puls

PULS PISA11.402 is a protection unit designed as a 4-channel protection module with 1 input and 4 outputs, suitable for DIN rail mounting. It operates within an ambient air temperature range of -25 to +70°C and adheres to NEC Class 2 design specifications. The rated current is 12A, distributed as 3A per channel, and it features screw-clamp connections for secure installation. As part of the PISA11-series, this unit measures 45mm in width, 75mm in height, and 91mm in depth. It requires a supply voltage of 18Vdc to 30Vdc, with 24Vdc typical and 21.4Vdc needed to activate the outputs. The output voltage is adjustable between 24Vdc and 28Vdc. Protection functions include short-circuit protection with a 10ms shutdown time and current limitation with an adjustable threshold between 16.6A and 23.6A. Power dissipation at full output load with a 24V input is 1.4W, and the processing time for output turn-on delay is 270ms. The voltage drop across the unit is 75mV / 0.075V. Electrical durability is rated at 229,000 hours at 40°C with a 4x1.5A output and 649,000 hours at 25°C with a 4x1.5A output.

4 in stock

Manufacturer warranty

PISA11.203206 Puls

Get a quick Quote!

Request a quote, and we will send you price and availability within minutes.

Select Qty:

Average response time: 11 minutes

Worldwide Shipping and Delivery

Secure Payment Processing

Warranty

Responsive Customer Support

Got Questions? We've Got Answers!

Need more details?

Feel free to chat with us

About the manufacturer

Puls

Powermatic Associates is an authorized Puls distributor, proudly offering their innovative and reliable industrial power supply solutions. Puls is a renowned manufacturer specializing in high-quality DIN rail power supplies, engineered to deliver optimal performance and efficiency across various demanding applications. Their product portfolio includes single-phase and three-phase power supplies, D...
