2966265 Phoenix Contact Control Relays
Part#:2966265
Manufacturer:Phoenix Contact
Category:Control Relays
Product Lifecycle:Active
Mar 14, 2025
Product description
PLC-INTERFACE, consisting of PLC-BSC.../21 basic terminal block with screw connection and plug-in miniature relay with multi-layer gold contact, for mounting on DIN rail NS 35/7,5, 1 changeover contact, input voltage 24 V DC6.2 mm PLC basic terminal block
Product Details
- Flammability rating according to UL 94 V0 (Housing)
- China RoHS Environmentally Friendly Use Period = 50 years
- ECLASS 4.1 27371100
- ETIM 2.0 EC001437
- ETIM 7.0 EC001437
- UNSPSC 12.01 39121515
- UNSPSC 19.0 39122334
- Designation Corrosive gas test
- ECLASS 10.0.1 27371601
- ECLASS 7.0 27371601
- UNSPSC 6.01 30211916
- UNSPSC 21.0 39122334
- Width 6.2 mm
- Depth 94 mm
- Degree of protection IP20 (Relay base)
- Ambient temperature (operation) -40 °C ... 60 °C
- Typical input current at UN 9 mA
- Typical release time 8 ms
- Operating voltage display Yellow LED
- Contact type 1 changeover contact
- Contact material AgSnO, hard gold-plated
- ECLASS 11.0 27371601
- ECLASS 6.0 27371600
- ETIM 3.0 EC001437
- UNSPSC 11 39121515
- UNSPSC 20.0 39122334
- Utilization restriction EMC: class A product, see manufacturer's declaration in the download area
- Height 80 mm
- Ambient temperature (storage/transport) -40 °C ... 85 °C
- Nominal input voltage UN 24 V DC
- Typical response time 5 ms
- Protective circuit Reverse polarity protection Polarity protection diode
- Power dissipation for nominal condition 0.22 W
- Type of switch contact Single contact
- Maximum switching voltage 250 V AC/DC
- Mounting position any
- Limiting continuous current 6 A
- Operating mode 100% operating factor
- Connection name Contact side
- Screw thread M3
- Standards/regulations IEC 60664
- Identification ISA-S71.04. G3 Harsh Group
- ECLASS 5.0 27371600
- ECLASS 4.0 27371100
- ECLASS 9.0 27371601
- ETIM 4.0 EC001437
- UNSPSC 13.2 39122334
- Connection method Screw connection
- Conductor cross section flexible 0.14 mm² ... 2.5 mm²
- Min. switching current 10 mA (at 12 V)
- Test voltage 4 kV AC (50 Hz, 1 min., winding/contact)
- Mechanical service life 2x 107 cycles
- Conductor cross section solid 0.14 mm² ... 2.5 mm²
- UNSPSC 18.0 39122334
- ETIM 6.0 EC001437
- Maximum inrush current 50 mA
- Note the following values are applicable if a gold layer is destroyed
- Stripping length 8 mm
- Conductor cross section AWG 26 ... 14
- Pollution degree 3
- REACh SVHC Lead 7439-92-1
- Minimum switching voltage 5 V (at 100 mA)
- Interrupting rating (ohmic load) max. 140 W (at 24 V DC)
- Switching capacity 2 A (at 24 V, DC13)
- Assembly instructions In rows with zero spacing
- Connection in acc. with standard CUL
- Overvoltage category III
- ECLASS 5.1 27371600
- UNSPSC 7.0901 39121515
