EX-13B

Panasonic

Product Lifecycle: Active

Panasonic EX-13B is a photo-electric sensor designed with a polyethylene terephthalate housing and a polyalylate lens. It operates with a current consumption of 10mA / 0.01 A for both the emitter and receiver. This sensor offers a degree of protection rated at IP67 and emits red light with a wavelength of 680 nm. It is capable of detecting opaque objects as small as 2mm / 0.079". The EX-13B features an orange LED that lights up when the output is ON and a green LED that indicates a stable light received or stable dark condition. It has a quick response time of 0.5ms / 0.0005 s and includes 1 digital output (NPN open-collector / 24Vdc / 50mA) for connectivity. The operating mode is Dark-ON, and it has a sensing distance of up to 0.5m / 50cm / 500mm / 19.685". This sensor is equipped with output short-circuit protection and is described as an ultra-slim photo-electric sensor emitter+receiver pair with front sensing and built-in amplification. For connection, it comes pre-wired with a 2m 3-core (2-core on emitter side) 0.1mm2 flexible cabtyre cable terminated with bare end flying leads.

EX-13B

Panasonic EX-13B is a photo-electric sensor designed with a polyethylene terephthalate housing and a polyalylate lens. It operates with a current consumption of 10mA / 0.01 A for both the emitter and receiver. This sensor offers a degree of protection rated at IP67 and emits red light with a wavelength of 680 nm. It is capable of detecting opaque objects as small as 2mm / 0.079". The EX-13B features an orange LED that lights up when the output is ON and a green LED that indicates a stable light received or stable dark condition. It has a quick response time of 0.5ms / 0.0005 s and includes 1 digital output (NPN open-collector / 24Vdc / 50mA) for connectivity. The operating mode is Dark-ON, and it has a sensing distance of up to 0.5m / 50cm / 500mm / 19.685". This sensor is equipped with output short-circuit protection and is described as an ultra-slim photo-electric sensor emitter+receiver pair with front sensing and built-in amplification. For connection, it comes pre-wired with a 2m 3-core (2-core on emitter side) 0.1mm2 flexible cabtyre cable terminated with bare end flying leads.
