601603CY Lapp Industrial Automation Components

601603CY on Powermatic Associates
Lapp

Part#:601603CY

Manufacturer:Lapp

Category:Industrial Automation Components

Product Lifecycle:Active

In-stock parts: 28

Dec 21, 2024

601603CY Lapp - ÖLFLEX 190 CY 3G1.5 16/3C

About the manufacturer: Lapp is one of the manufacturers that offers Industrial Automation Components that you can order at Powermatic Associates site. Lapp Group is a leading worldwide provider of premium cables, wires, cable accessories, and systems.

Check out the 601603CY Lapp price in the box on the right side or send a quick quote.

Product Details

  • Voltage
    600 volts
  • Operating Temperature
    -40 degrees celsius, 105 degrees celsius
  • Stranding
    Class 5 Fine Wire
  • Jacket Material
    Thermoplastic Polymer
  • Jacket Color
    Gray
  • Gauge
    16 american wire gauge
  • Insulation Material
    PVC
  • Conductor Material
    Finely Stranded Bare Copper
  • Bend Radius
    6 X Cable Diameter
  • UL STYLE / STANDARD
    UL 13 UL 2277
  • WEIGHT LBS/MFT
    115
  • MANUFACTURER PART NUMBER
    601603CY
  • STANDARDS/APPROVALS
    UL Approved CSA Approved CE Approved
  • TRAY RATINGS
    UL TC-ER
  • ATTRIBUTES
    UL Oil Res I/IISunlight resistant Direct burialNFPA 79
  • DYNAMIC TEMPERATURE RATING
    -13°F to +194°F-25°C to +90°C
  • STATIC TEMPERATURE RATING
    -40°F to +221°F-40°C to +105°C
  • TEMPERATURE
    -13°F to +194°F -25°C to +90°C
  • NOMINAL OD (MM)
    10
  • VOLTAGE
    600V
  • INSULATION
    PVC
  • CONDUCTOR STRANDING
    Stranded
  • NOMINAL OD (IN)
    0.395
  • AWG/GAUGE
    16
  • JACKET MATERIAL
    Thermoplastic Polymer
  • SHIELDING
    Braid
  • CONDUCTOR MATERIAL
    Bare copper
  • JACKET COLOR
    Gray
  • CONDUCTOR COLOR
    Black with white printing plus green/yellow ground
  • NUMBER OF CONDUCTORS
    3
  • SERIES
    ÖLFLEX® 190 / 190 CY

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.


601603CY Description

Cable, Flexible, ÖLFLEX 190 CY, 16 AWG/3C, Shielded, 600V, UL TC-ER, UL AWM, CSA AWM FT4
