40.52.9.024.0000 Finder Control Relays

40.52.9.024.0000 on Powermatic Associates
Finder

Part#:40.52.9.024.0000

Manufacturer:Finder

Category:Control Relays

Product Lifecycle:Active

11 in stock

Apr 1, 2025

Product description

Finder 40.52.9.024.0000 is a relay with solder pin connection type, designed for a rated current of 8A at 250Vac (AC-1) and 8A at 30Vdc (DC-1), with lower current ratings of 0.6A at 110Vdc and 0.3A at 220Vdc for Normally Open (NO) auxiliary contacts. It operates with a supply voltage of 2C/O / DPDT (Double Pole Double Throw), capable of handling ambient air temperatures from -40 to +85 degrees Celsius for operation and has a rated voltage for AC operations. The relay features a net width of 24Vdc, a net depth of 25 mm, and a mounting mode length of 29 mm, with a 2 Pole(s) rated active power configuration. Power consumption is noted at 0.65 W, with a response time also at 0.65 W. It includes a visual position indicator with 5.3mm pins pitch, supports up to 100,000 operations for Normally Closed (NC) circuits, and is designed for up to 10,000,000 operations. The relay's construction includes AgNi (Silver Nickel) contacts, with a control voltage (AC) of 6 kV, and it is suitable for PCB or plug-in mounting.

Product Details

  • Primary brand
    Finder
  • Rated power
    750VA (230Vac; AC-15) 2000VA (250Vac; AC-1) 0.65W
  • Rated voltage (AC)
    250Vac
  • Degree of protection
    RT II
  • Compliant with standard(s)
    cURus Lloyd Register (LR) CCC RINA IMQ CSA VDE EAC EN 60335-1 EN 60664-1 EN 60715 EN 61000-4-5 EN 61810-1
  • Net Width (mm)
    29 mm
  • Distance
    5.3mm pins pitch
  • Connection type
    Solder pin
  • Ambient air temperature for operation
    -40...+85 °C
  • Mechanical durability (at no load)
    10 000 000 operations
  • Product series / family name
    40 series
  • Main function
    Relay
  • Control Voltage (DC)
    24Vdc
  • Mounting mode
    PCB Plug-in
  • Electrical durability (with load)
    100 000 operations
  • Contacts coating
    AgNi (Silver Nickel)
  • Rated current
    8A (250Vac; AC-1) 8A (30Vdc; DC-1) 0.6A (110Vdc; DC-1) 0.3A (220Vdc; DC-1)
  • Contacts type
    2C/O / DPDT (Double Pole Double Throw)
  • Rated impulse voltage (Uimp)
    6 kV
  • Net Depth (mm)
    12.4 mm
  • Poles
    2 Pole(s)
  • Power consumption
    0.65 W
  • Net Height (mm)
    25 mm

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

40.52.9.024.0000 Related Documents

Finder - 40 Series - Catalogue.pdf
