9800 Festo Pneumatic Components

9800 on Powermatic Associates
Festo

Part#:9800

Alt. Part#:SEU-3/8-NPT

Manufacturer:Festo

Category:Pneumatic Components

Product Lifecycle:Active

Product description

quick exhaust valve SEU-3/8-NPT With built-in silencer. Valve function: Quick exhaust, Pneumatic connection, port 1: 3/8 NPT, Pneumatic connection, port 2: 3/8 NPT, Mounting type: Threaded, Standard nominal flow rate, exhaust: 2280 l/min

Product Details

  • Type code
    SEU
  • Pneumatic connection 2
    3/8 NPT
  • Standard flow rate exhaust 6-> 0 bar
    4680 l/min
  • Operating pressure
    0.2 bar ... 10 bar
  • Noise level
    83 dB(A)
  • Pneumatic connection 1
    3/8 NPT
  • Ambient temperature
    -20 °C ... 75 °C
  • Symbol
    00991460
  • Temperature of medium
    -20 °C ... 75 °C
  • Note on materials
    RoHS-compliant
  • Valve function
    Quick exhaust
  • Standard nominal flow rate exhaust air 6->5 bar
    2280 l/min
  • Operating medium
    Compressed air as per ISO 8573-1:2010 [7:-:-]
  • Information on operating and pilot media
    Operation with oil lubrication possible (required for further use)
  • Selection of additional function
    With pneumatic muffler
  • Standard nominal flow rate pressurization 6->5 bar
    2880 l/min
  • Type of mounting
    Screw-in
  • Nominal width
    11 mm

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

9800 Related Documents

9800 DataSheet.pdf
