8997 Festo Mechanical & Manual Valves

Festo 8997 foot valve with detent FP-5-1/4-B detenting Valve function: 5/2 bistable, Type of actuation: manual, Standard nominal flow rate: 550 l/min, Operating pressure: -0,95 - 10 bar, Design structure: Poppet seat
Festo

Part#:8997

Manufacturer:Festo

Alt. Part#:FP-5-1/4-B

Product Lifecycle:Active

Get a quick Quote!

foot valve with detent FP-5-1/4-B detenting Valve function: 5/2 bistable, Type of actuation: manual, Standard nominal flow rate: 550 l/min, Operating pressure: -0,95 - 10 bar, Design structure: Poppet seat

About the manufacturer: Festo is one of the manufacturers that offers Mechanical & Manual Valves that you can order at Powermatic Associates site. Festo Corp. has been a top supplier of automation and intelligent automation solutions for more than four decades in the United States and eight decades globally. The company is committed to transforming the manufacturing sector and enhancing business efficiency.

Check out the 8997 Festo price in the box on the right side or send a quick quote.

Product Details

  • Type code
    FP
  • Flow direction
    Non-reversible
  • Pneumatic connection 1
    G1/4
  • Standard nominal flow rate
    550 l/min
  • Valve function
    5/2, bistable
  • Pneumatic working port
    G1/4
  • Operating pressure
    -0.95 bar ... 10 bar
  • Type of control
    Direct
  • Type of mounting
    With through-hole
  • Pneumatic connection 4
    G1/4
  • Seals material
    NBR
  • Actuation type
    Manual
  • Design
    Plate seat
  • Mounting position
    Any
  • Symbol
    00991334
  • Ambient temperature
    -10 °C ... 60 °C
  • Pneumatic connection 2
    G¼
  • Pneumatic connection 5
    G1/4
  • Reset method
    Mechanical spring
  • Nominal width
    7 mm
  • Actuating force
    82 N
  • Pneumatic connection 3
    G1/4
  • Operating medium
    Compressed air as per ISO 8573-1:2010 [7:4:4]
  • Product weight
    1845 g
  • Housing material
    Die-cast aluminum

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

Related documents 8997 Specs

8997 8997 DataSheet.pdf
