8117023 Festo Pinch Valves

8117023 on Powermatic Associates
Festo

Part#:8117023

Alt. Part#:VZQA-C-M22C-6-S1S1-V2V4&

Manufacturer:Festo

Category:Pinch Valves

Product Lifecycle:Active

Product description

Pinch valve VZQA-C-M22C-6-S1S1-V2V4&

Product Details

  • Type code
    VZQA
  • Actuation type
    Pneumatic
  • Nominal width DN
    6
  • Valve function
    2/2, closed, monostable
  • Medium pressure
    0 bar ... 2 bar
  • Fitting connection
    Clamp as per ASME-BPE, type A
  • Type of control
    Externally controlled
  • Medium
    Compressed air as per ISO 8573-1:2010 [-:-:1] Water
  • On switching time
    125 ms
  • Switching time off
    125 ms
  • Product weight
    302 g
  • Operating pressure
    3.5 bar ... 6 bar
  • Mounting position
    Any
  • Flow direction
    Reversible
  • Auxiliary pilot air port 12
    M3
  • Temperature of medium
    -5 °C ... 90 °C
  • Flow rate Kv
    0.7 m³/h
  • Material no. housing cover
    1.4435
  • Material of bowl
    PPS
  • Burst pressure
    16 bar
  • Design
    Pinch valve, pneumatically operated
  • Type of mounting
    Line installation
  • Reset method
    Mechanical spring
  • Pilot medium
    Compressed air as per ISO 8573-1:2010 [7:4:1]
  • Ambient temperature
    -5 °C ... 60 °C
  • Housing material
    High-alloy stainless steel
  • Shut-off element material
    VMQ (silicone)
  • Sealing principle
    Soft
  • Nominal pressure of fitting PN
    10
  • Symbol
    00992981
  • Storage temperature
    5 °C ... 30 °C
  • Note on materials
    Contains paint-wetting impairment substances RoHS-compliant
  • Housing cover material
    High-alloy stainless steel
  • Max. viscosity
    4000 mm²/s
  • Material number of housing
    1.4301
  • Seals material
    FPM
  • For use in the food industry
    See supplementary material information

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
