8116807 Festo Pneumatic Grippers

Product Details

• Stroke per gripper jaw
  6 mm
• Pneumatic gripper repetition accuracy
  ≤ 0.02 mm
• Gripper function
  Parallel
• Symbol
  00991894
• Min. opening time at 6 bar
  40 ms
• Corrosion resistance class (CRC)
  0 - No corrosion stress
• Gripping force per gripper jaw at 6 bar, closing
  53.9 N
• Operating pressure
  1 bar ... 8 bar
• Max. gripper jaw backlash Sz
  0 mm
• Type code
  DHPC
• Total gripping force at 6 bar, opening
  125.4 N
• Housing material
  Aluminum, anodized
• Rotational symmetry
  ≤ 0.2 mm
• Mode of operation
  Double-acting
• Guide
  Ball guide
• Min. closing time at 6 bar
  40 ms
• Ambient temperature
  -10 °C ... 60 °C
• Maximum force on gripper jaw Fz, static
  49 N
• Product weight
  124 g
• Gripper jaw material
  High-alloy stainless steel
Max. interchangeability
0.2 mm
Number of gripper jaws
2
Position sensing
For proximity sensor
Operating medium
Compressed air as per ISO 8573-1:2010 [7:4:4]
Mass moment of inertia
0.215 kgcm²
Maximum torque on gripper jaw, Mz static
0.34 Nm
Pneumatic connection
M3
Size
16
Max. gripper jaw angular play ax, ay
0 deg
Mounting position
Any
Design
Connection direction downwards Positively driven motion sequence
Total gripping force at 6 bar, closing
107.8 N
Max. operating frequency of pneumatic gripper
3 Hz
Information on operating and pilot media
Operation with oil lubrication possible (required for further use)
Gripping force per gripper jaw at 6 bar, opening
62.7 N
Maximum torque on gripper jaw, Mx static
0.34 Nm
Max. mass per external gripper finger
360 g
Type of mounting
Optionally: With internal thread and dowel pin
Maximum torque on gripper jaw, My static
0.68 Nm
Note on materials
Free of copper and PTFE RoHS-compliant
