8109395 Festo Pneumatic Valves Accessories

8109395 on Powermatic Associates
Festo

Part#:8109395

Alt. Part#:VACC-S18-120-K4-1U-EX4ME

Manufacturer:Festo

Category:Pneumatic Valves Accessories

Product Lifecycle:Active

Product description

solenoid coil VACC-S18-120-K4-1U-EX4ME Type of actuation: electrical, Assembly position: Any, Switching position indicator: No, Duty cycle: 100 %, Insulation class: H

Product Details

  • Duty cycle
    100%
  • ATEX category gas
    II 2G
  • Type of (ignition) protection for dust
    Ex tb IIIC T120°C Db
  • Electrical connection
    Terminal box, cable entry thread M20x1.5
  • Insulation class
    H
  • Coil characteristics
    24 V AC: 50/60 Hz, power 12.0 VA 24 V DC: 12.0 W
  • Explosion protection certification outside the EU
    EPL Db (IEC-EX) EPL Gb (IEC-EX)
  • CE marking (see declaration of conformity)
    as per EU explosion protection directive (ATEX)
  • Type code
    VACC
  • Switching position indication
    no
  • ATEX category for dust
    II 2D
  • Explosion prevention and protection
    Zone 1 (ATEX) Zone 21 (IEC-EX)
  • Degree of protection
    IP66
  • Mounting position
    Any
  • Permissible voltage fluctuations
    -15 % / +10 %
  • Type of ignition protection for gas
    Ex eb mb IIC T4 Gb
  • Explosive ambient temperature
    T4, T120°C: -25°C <= Ta <= +40°C
  • Product weight
    580 g
  • Actuation type
    Electrical
  • Certificate issuing authority
    BVS 16ATEXE036X IECEx BVS16.0028X
  • Note on materials
    Contains paint-wetting impairment substances RoHS-compliant

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
