8082990 Festo Fluid Control Actuator Accessories

Name: 8082990
Brand: Festo

Part#:8082990

Alt. Part#:DARQ-B-F12-F10-R13

Manufacturer:Festo

Category:Fluid Control Actuator Accessories

Product Lifecycle:Active

Product description

mounting bridge DARQ-B-F12-F10-R13 Container size: 1, Design structure: Mounting adapter, Corrosion resistance classification CRC: 2 - Moderate corrosion stress, Product weight: 1688 g, Connection 1, function: Drive outlet

Product Details

Connection 1, function
Actuator outlet
Type code
DARQ
Mounting adapter material
Steel, galvanized
Connection 2, design
Hole pattern 10
Connection 2, function
Reducing outlet
Product weight
1688 g
Connection 1, design
Hole pattern 12
Design
Mounting adapter
Pack size
1
Corrosion resistance class (CRC)
2 - Moderate corrosion stress
Note on materials
Contains paint-wetting impairment substances RoHS-compliant

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

8082990 Related Documents

8082990 DataSheet.pdf

Manufacturer warranty

8082990 Festo
