8074191 Festo Cable Assemblies

Product Details

• Cable designation
  With 2x label holders
• Contact durability
  100
• Electrical connection 1, design
  Round
• Electrical connection 1, connection technology
  M12x1 A-coded as per EN 61076-2-101
• Electrical connection 2, connection technology
  Open end
• Connector cable test conditions
  Test conditions on request
• Cable diameter tolerance
  ± 0.3 mm
• Nominal conductor cross section
  0.25 mm² 0.34 mm²
• Contamination level
  3
• Material of screw-type lock
  Die-cast zinc, nickel-plated
• Electrical connection 1, cable outlet
  Straight
• Electrical connection 1, type of mounting
  Screw-type lock
• Electrical connection 2, connection type
  Cable
• Current rating at 40°C
  4 A
• Bending radius, flexible cable installation
  ≥ 70 mm
• Degree of protection
  IP65 IP67
• Note on degree of protection
  In mounted state
• Housing material
  TPE-U(PUR), reinforced
• Material of pin contacts
  Brass, nickel-plated and gold-plated
• Type code
  NEBC
Electrical connection 1, function
Field device end
Electrical connection 1, number of pins/wires
5
Electrical connection for input 1, connection pattern
00995384
DC operating voltage range
0 V ... 30 V
Bending radius, fixed cable installation
≥ 35 mm
Cable diameter
6.7 mm
Ambient temperature with flexible cable installation
-20 °C ... 80 °C
Housing colour
Black
Product weight
310.7 g
Electrical connection 1, occupied pins/wires
5
Electrical connection 2, function
Control side
Electrical connection 2, number of pins/wires
5
Surge resistance
2 kV
Cable characteristic
Suitable for energy chains
Wire ends
Stripped
Ambient temperature
-25 °C ... 80 °C
Material of cable sheath
TPE-U(PUR)
Seals material
NBR
Insulating sheath material
PE
Protocol
CANopen DeviceNet
Electrical connection 1, connection type
Socket
Electrical connection 2, occupied pins/wires
5
Cable length
5 m
Cable design
(2 x 0.34 mm²) + (2 x 0.25 mm²) + 0.34 mm² Shielded
Note on materials
RoHS-compliant
Color cable sheath
Red-purple
