8070257 Festo Ball Valves

8070257 on Powermatic Associates
Festo

Part#:8070257

Alt. Part#:VZBM-A-2"-RP-25-F-3L-B2-PA80

Manufacturer:Festo

Category:Ball Valves

Product Lifecycle:Active

Product description

ball valve actuator unit VZBM-A-2"-RP-25-F-3L-B2-PA80 Brass, with double-acting actuator DFPD 3/2-way, nominal width 2", PN25, thread EN 10226-1. Design structure: (* 3-way ball valve, * Swivel drive), Type of actuation: pneumatic, Assembly position: Any,

Product Details

  • Type of mounting
    Line installation
  • Fitting connection
    Rp2
  • Nominal pressure of fitting PN
    25
  • Temperature of medium
    -20 °C ... 130 °C
  • Housing material
    Brass, nickel-plated
  • Material number for shaft
    CW614N
  • Type code
    VZBM
  • Operating pressure
    5.5 bar ... 8 bar
  • Information on operating and pilot media
    Dew point min. 10 °C below the ambient and medium temperature Operation with oil lubrication possible (required for further use)
  • Flow rate Kv type L
    292 m³/h
  • Material number for ball
    CW614N
  • Ball material
    Brass, chrome-plated
  • Nominal width DN
    50
  • Operating medium
    Compressed air as per ISO 8573-1:2010 [7:4:4]
  • Material number of housing
    CW617N
  • Product weight
    7807 g
  • Design
    3-way ball valve Quarter turn actuator
  • Mounting position
    Any
  • Medium
    Compressed air as per ISO 8573-1:2010 [-:-:-] Neutral liquids
  • Note on materials
    Contains paint-wetting impairment substances RoHS-compliant
  • Corrosion resistance class (CRC)
    1 - Low corrosion stress
  • Actuation type
    Pneumatic
  • Switching position indication
    Slot direction = flow direction
  • Symbol
    00991921
  • Ambient temperature
    -20 °C ... 80 °C
  • Seals material
    HNBR PTFE
  • Shaft material
    Brass

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
