8070256 Festo Ball Valves
Part#:8070256
Alt. Part#:VZBM-A-11/2"-RP-25-F-3L-B2-PA80
Manufacturer:Festo
Category:Ball Valves
Product Lifecycle:Active
Product description
ball valve actuator unit VZBM-A-11/2"-RP-25-F-3L-B2-PA80 Brass, with double-acting actuator DFPD 3/2-way, nominal width 11/2", PN25, thread EN 10226-1. Design structure: (* 3-way ball valve, * Swivel drive), Type of actuation: pneumatic, Assembly position
Product Details
- Mounting position Any
- Switching position indication Slot direction = flow direction
- Operating pressure 5.5 bar ... 8 bar
- Temperature of medium -20 °C ... 130 °C
- Housing material Brass, nickel-plated
- Shaft material Brass
- Product weight 6597 g
- Actuation type Pneumatic
- Type of mounting Line installation
- Medium Compressed air as per ISO 8573-1:2010 [-:-:-] Neutral liquids
- Nominal width DN 40
- Flow rate Kv type L 200 m³/h
- Material number of housing CW617N
- Ball material Brass, chrome-plated
- Type code VZBM
- Fitting connection Rp1 1/2
- Information on operating and pilot media Dew point min. 10 °C below the ambient and medium temperature Operation with oil lubrication possible (required for further use)
- Material number for ball CW614N
- Corrosion resistance class (CRC) 1 - Low corrosion stress
- Design 3-way ball valve Quarter turn actuator
- Symbol 00991921
- Ambient temperature -20 °C ... 80 °C
- Seals material HNBR PTFE
- Nominal pressure of fitting PN 25
- Operating medium Compressed air as per ISO 8573-1:2010 [7:4:4]
- Note on materials Contains paint-wetting impairment substances RoHS-compliant
- Material number for shaft CW614N
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
