8049049 Festo Pneumatic Components

Product Details

• Electrical connection input, function
  Ejector pulse Vacuum generator
• Electrical connection output, connection technology
  Open end
• Cable diameter tolerance
  ± 0.1 mm
• Electrical output connection, number of pins/wires
  3
• Nominal conductor cross section
  0.14 mm²
• Electrical connection input, connection type
  2x plugs
• Electrical connection output, connection type
  Cable
• Cable characteristic
  Suitable for energy chains
• Color cable sheath
  Gray
• Electrical connection, input, number of pins/wires
  2
• Type code
  OVEL
• Integrated function
  Electric ejector pulse Pneumatic muffler open
• Valve function
  Closed
• Max. vacuum
  89 %
• Max. suction rate with respect to atmosphere
  4 l/min
• Corrosion resistance class (CRC)
  2 - Moderate corrosion stress
• Product weight
  71 g
• Pneumatic connection 1
  for pneumatic tubing outside diameter 4 mm
• Seals material
  NBR
• Housing material
  PA-reinforced
Electrical connection for input, connection pattern
00995626
Analog output
0 - 10 V
Method of measurement
Piezoresistive pressure sensor
Nominal width of Laval nozzle
0.45 mm
DC sensor operating voltage range
18 V ... 30 V
Muffler construction type
Open
Grade of filtration
40 µm
Nominal operating pressure
4 bar
Duty cycle
100%
CE marking (see declaration of conformity)
As per EU EMC directive
Degree of protection
IP40
Vacuum connection
For pneumatic tubing outside diameter 4 mm
Muffler material
PE
Electrical connection output, function
Sensor
Material of cable sheath
PVC
Electrical input connection, connection technology
Connection diagram H
Cable diameter
2.9 mm
Width dimension
10 mm
Ejector characteristics
High vacuum Standard
Symbol
00995804
Operating pressure for max. suction rate
3 bar
Information on operating and pilot media
Operation with oil lubrication not possible
Temperature of medium
0 °C ... 50 °C
Pressure measuring range
-1 bar ... 0 bar
Compressed air filter material
POM
Material of jet nozzle
Wrought aluminum alloy
Electrical input connection, mounting type
Snap-locking
KC characters
KC EMC
Cable length
2.5 m
Manual override
Non-detenting
Operating pressure
2 bar ... 7 bar
Coil characteristics
24 V DC: 1.0 W
Noise level at nominal operating pressure
64 dB(A)
Type of mounting
With through-hole
Material of connecting thread
POM
Note on materials
RoHS-compliant
Material of screws
Steel
Air supply time at nominal operating pressure with ejector pulse
2 s
Mounting position
Any
Design
T-shape
Operating pressure for max. vacuum
4.2 bar
DC operating voltage range
21.6 V ... 26.4 V
Operating medium
Compressed air as per ISO 8573-1:2010 [7:4:4]
Ambient temperature
0 °C ... 50 °C
Pneumatic connection 3
Pneumatic muffler open
Female nozzle material
POM
Material of adjusting screw
Steel
