8036888 Festo Flow Sensors

8036888 on Powermatic Associates
Festo

Part#:8036888

Alt. Part#:SFAW-32T-X-E-PNLK-PNVBA-M12

Manufacturer:Festo

Category:Flow Sensors

Product Lifecycle:Active

Product description

flow sensor SFAW-32T-X-E-PNLK-PNVBA-M12 Authorisation: (* RCM Mark, * c UL us - Listed (OL)), CE mark (see declaration of conformity): (* to EU directive for EMC, * in accordance with EU RoHS directive), KC mark: KC-EMV, Materials note: Conforms to RoHS,

Product Details

  • Flow measuring range end value
    32 l/min
  • Certification
    RCM compliance mark c UL us - Listed (OL)
  • Flow measuring range start value
    1.8 l/min
  • Operating medium
    Liquid media Neutral liquids
  • Nominal temperature
    23 °C
  • Temperature co-efficient margin in ± %FS/K
    Typ. ±0.05% FS/K
  • Analog output
    0 - 10 V 1 - 5 V
  • Temperature characteristic curve end value
    100 °C
  • IO-Link®, profile
    Smart sensor profile
  • IO-Link®, SIO mode support
    Yes
  • IO-Link®, service data contents IN
    32 bit volume measurement
  • IO-Link®, data memory required
    500 byte
  • Fluid connector
    Connection provided by the user
  • Materials in contact with the media
    EPDM (peroxide) PA6T/6I-reinforced
  • Symbol
    00995566
  • Ambient temperature
    0 °C ... 50 °C
  • Switching element function
    N/C contact/N/O contact switchable
  • Max. load resistance of current output
    500 Ohm
  • Overload protection
    Available
  • IO-Link®, function classes
    Binary data channel (BDC) Teach channel
  • IO-Link®, process data content IN
    1 bit BDC (temperature monitoring) 2 bit BDC (flow monitoring)
  • Reverse polarity protection
    for all electrical connections
  • Product weight
    140 g
  • Type code
    SFAW
  • CE marking (see declaration of conformity)
    As per EU EMC directive As per EU RoHS directive
  • Flow direction
    Unidirectional P1 -> P2
  • Temperature measuring range end value
    90 °C
  • Information on operating and pilot media
    Media with a kinematic viscosity = 1.8 mm²/sec. [cSt]. Compatibility of the media with the substances that come into contact with the media must be ensured.
  • Accuracy of flow rate
    ±2 % FS for flow rate <= 50 % FS ±3 % o.m.v. for flow rate >= 50 %FS
  • Switching output
    2 x PNP or 2 x NPN switchable
  • Flow characteristic curve, end value
    32 l/min
  • Min. load resistance of voltage output
    15 kOhm
  • Protocol
    IO-Link®
  • IO-Link®, port class
    A
  • IO-Link®, process data width IN
    5 Byte
  • Electrical connection
    5-pin Plug, straight
  • Housing material
    PA-reinforced
  • Corrosion resistance class (CRC)
    3 - High corrosion stress
  • KC characters
    KC EMC
  • Note on materials
    RoHS-compliant
  • Method of measurement
    Flow rate: vortex Temperature: PT1000
  • Information on operating pressure
    Max. 12 bar at 40°C Max. 6 bar at 100 °C
  • Temperature of medium
    0 °C ... 90 °C
  • Accuracy of temperature in ± °C
    2 °C
  • Switching function
    Window comparator Freely programmable
  • Max. output current
    100 mA
  • Temperature characteristic curve start value
    0 °C
  • IO-Link®, protocol version
    Device V 1.1
  • IO-Link®, process data width OUT
    0 Byte
  • DC operating voltage range
    18 V ... 30 V
  • Max. cable length
    20 m for IO-Link® operation 30 m
  • Displayable unit(s)
    US gal °F
  • Measured variable
    Flow rate Temperature
  • Temperature measuring range start value
    0 °C
  • Operating pressure
    0 bar ... 12 bar
  • Repetition accuracy of flow rate value
    < ±0.5 % FS for flow rate <= 50 % FS < ±1 % o.m.v. for flow rate >= 50 %FS
  • Flow characteristic curve, start value
    0 l/min
  • Short-circuit protection
    yes
  • IO-Link®, communication mode
    COM2 (38,4 kBd)
  • IO-Link®, minimum cycle time
    5 ms
  • Mounting position
    Any
  • Degree of protection
    IP65

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
