8031111 Festo Proportional Valves

Product Details

• Type of control
  Pilot-controlled
• Pressure regulation range
  0.06 bar ... 6 bar
• Max. current consumption
  300 mA
• Residual ripple
  10 %
• Corrosion resistance class (CRC)
  2 - Moderate corrosion stress
• Linearity error FS
  1 %
• IO-Link®, communication mode
  COM1 (4.8 kBd), COM2 (38.4 kBd), COM3 (230.4 kBd)
• IO-Link®, minimum cycle time
  0.5 ms
• Note on materials
  RoHS-compliant
• Ambient temperature
  0 °C ... 60 °C
• Nominal width pressurization
  8 mm
• Mounting position
  Any
• Symbol
  00995303
• Display type
  LED
• Duty cycle
  100%
• CE marking (see declaration of conformity)
  As per EU EMC directive
• Temperature of medium
  10 °C ... 50 °C
• Temperature coefficient
  0.04 %/K
• Repetition accuracy FS
  0.5 %
• IO-Link®, process data width IN
  2 Byte
Housing material
Wrought aluminum alloy Anodized
KC characters
KC EMC
Actuation type
Electrical
Sealing principle
Soft
Safety instructions
VPPM safety position: if the supply cable breaks, the outlet pressure is maintained in uncontrolled form.
Inlet pressure 1
0 bar ... 8 bar
Standard nominal flow rate
1050 l/min
Protocol
I-Port IO-Link®
IO-Link®, protocol version
Device V 1.1
Pneumatic connection 1
Sub-base
Type code
VPPM
Short-circuit protection
For all electrical connections
Reset method
Mechanical spring
Reverse polarity protection
for all electrical connections
Max. pressure hysteresis
0.03 bar
Operating medium
Compressed air as per ISO 8573-1:2010 [7:4:4] Inert gas
Degree of protection
IP65
Certification
RCM compliance mark c UL us - Listed (OL)
IO-Link®, process data width OUT
2 Byte
Type of mounting
Optionally: With accessories
Pneumatic connection 2
Sub-base
Exhaust nominal width
7 mm
Design
Pilot-controlled diaphragm regulator
Valve function
3-way proportional pressure control valve
DC operating voltage range
18 V ... 30 V
Max. electrical power consumption
7 W
Information on operating and pilot media
Operation with oil lubrication not possible
Product weight
560 g
IO-Link®, port class
A
Pneumatic connection 3
Sub-base
