8005312 Festo Cable Assemblies

8005312 on Powermatic Associates
Festo

Part#:8005312

Manufacturer:Festo

Category:Cable Assemblies

Alt. Part#:NEDY-L2R1-V1-M8G3-N-M8G4

Product Lifecycle:Active

Get a quick Quote!

distributor NEDY-L2R1-V1-M8G3-N-M8G4 Based on the standard: EN 61076-2-104, Design structure: Y-distributor without cable, Distributor type: 2 to 1, Cable identification: Without inscription label holder, Mounting type: (* With through-hole for M2 screw,

About the manufacturer: Festo is one of the manufacturers that offers Cable Assemblies that you can order at Powermatic Associates site. Festo Corp. has been a top supplier of automation and intelligent automation solutions for more than four decades in the United States and eight decades globally. The company is committed to transforming the manufacturing sector and enhancing business efficiency.

Check out the 8005312 Festo price in the box on the right side or send a quick quote.

Product Details

  • Design
    Y-distributor without cable
  • Type of mounting
    With through-hole for M2 screw With accessories
  • Product weight
    27 g
  • Electrical connection 1, connection technology
    M8x1 A-coded as per EN 61076-2-104
  • Electrical connection 2, function
    Field device end
  • Electrical connection 2, occupied pins/wires
    3
  • Current rating at 40°C
    3 A
  • Surge resistance
    0.8 kV
  • Corrosion resistance class (CRC)
    2 - Moderate corrosion stress
  • Threaded sleeve material
    Brass, nickel-plated
  • Type code
    NEDY
  • Distributor type
    2 to 1
  • Electrical connection 1, design
    Round
  • Electrical connection for input 1, connection pattern
    00991171
  • Electrical connection 1, occupied pins/wires
    4
  • Electrical connection 2, cable outlet
    Straight
  • Electrical connection 2, connection pattern
    00991871
  • Note on ambient temperature
    -10 - 40 °C when mounted via through-hole
  • Storage temperature
    -25 °C ... 85 °C
  • Housing colour
    Black
  • Based on norm
    EN 61076-2-104
  • Cable designation
    Without label holder
  • Electrical connection 1, cable outlet
    Straight
  • Electrical connection 2, design
    Round
  • Electrical connection 2, number of pins/wires
    3
  • DC operating voltage range
    0 V ... 30 V
  • Ambient temperature
    -25 °C ... 85 °C
  • Color cable sheath
    Gray
  • Material of union nut
    Brass, nickel-plated
  • Material of pin contacts
    Copper alloy, gold-plated
  • Degree of protection
    IP65 IP69K
  • Contamination level
    3
  • Seals material
    NBR
  • Explosion prevention and protection
    Observe the information on the certificate Zone 22 (ATEX)
  • Electrical connection 1, function
    Control side
  • Electrical connection 1, connection type
    Plug
  • Electrical connection 1, number of pins/wires
    4
  • Electrical connection 2, connection type
    2x socket
  • Electrical connection 2, connection technology
    M8x1 A-coded as per EN 61076-2-104
  • Operating voltage range AC
    0 V ... 30 V
  • Note on materials
    Free of copper and PTFE Free of phosphoric acid ester
  • Material of cable sheath
    TPE-U(PUR)
  • Housing material
    PC TPE-U(PUR)

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
