8005066 Festo Quarter Turn Actuators
Part#:8005066
Manufacturer:Festo
Alt. Part#:DAPS-0960-090-RS1-F14-MW
Product Lifecycle:Active
Get a quick Quote!
semi-rotary drive DAPS-0960-090-RS1-F14-MW single-acting, air connection to VDI/VDE 3845 Namur valves, direct flange mounting, version with handwheel. Size of actuator: 0960, Flange hole pattern: F14, Swivel angle: 92 deg, Shaft connection depth: 48,5 mm,
About the manufacturer: Festo is one of the manufacturers that offers Quarter Turn Actuators that you can order at Powermatic Associates site. Festo Corp. has been a top supplier of automation and intelligent automation solutions for more than four decades in the United States and eight decades globally. The company is committed to transforming the manufacturing sector and enhancing business efficiency.
Check out the 8005066 Festo price in the box on the right side or send a quick quote.
Product Details
- Size of valve actuator 0960
- Type code DAPS
- Cushioning No cushioning
- Safety integrity level (SIL) Up to SIL 2 high demand mode Up to SIL 2 low demand mode
- Flange hole pattern F14
- Standard connection for valve ISO 5211
- Position sensing None
- Valve connection conforms to standard VDI/VDE 3845 (NAMUR)
- Symbol 00991266
- ATEX category for dust II 2D
- Spring force 1
- Shaft connection T46
- Material of screws High-alloy steel
- Swivel angle 92 deg
- Information on the end-position adjusting range One end position optionally adjustable
- Design Scotch yoke system
- Connection pressure for spring force 2.8 bar
- Nominal operating pressure 5.6 bar
- Type of (ignition) protection for dust Ex h IIIC T85°C...T200°C Db X
- Information on operating and pilot media Operation with oil lubrication possible (required for further use)
- Spring return torque at 0° swivel angle 320 Nm
- Air consumption at 6 bar per cycle 0°-nominal swivel angle-0° 41.3 l
- Note on materials RoHS-compliant
- Housing material Wrought aluminum alloy
- Material number for shaft 1.4305
- Mounting position Any
- Explosion prevention and protection Zone 1 (ATEX) Zone 22 (ATEX)
- Corrosion resistance class (CRC) 2 - Moderate corrosion stress
- Spring return torque with 50° swivel angle 240 Nm
- Product weight 50600 g
- Cover material Wrought aluminum alloy
- Depth shaft connection 48.5 mm
- Mode of operation Single-acting
- Closing direction Clockwise closing
- ATEX category gas II 2G
- Explosive ambient temperature -50°C <= Ta <= +60°C
- CE marking (see declaration of conformity) as per EU explosion protection directive (ATEX)
- Spring return torque with 90° swivel angle 480 Nm
- Pneumatic connection G1/4
- Shaft material High-alloy steel
- Operating pressure 2.8 bar ... 8.4 bar
- Type of ignition protection for gas Ex h IIC T6...T3 Gb X
- Ambient temperature -20 °C ... 80 °C
- Operating medium Compressed air as per ISO 8573-1:2010 [7:4:4]
- Seals material FPM PUR
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
