6755 Festo Pneumatic Components

6755 on Powermatic Associates
Festo

Part#:6755

Alt. Part#:SEU-3/8

Manufacturer:Festo

Category:Pneumatic Components

Product Lifecycle:Active

Product description

quick exhaust valve SEU-3/8 With built-in silencer. Valve function: Quick exhaust, Pneumatic connection, port 1: G3/8, Pneumatic connection, port 2: G3/8, Mounting type: Threaded, Standard nominal flow rate, exhaust: 2280 l/min

Product Details

  • Pneumatic connection 1
    G3/8
  • Operating pressure
    0.2 bar ... 10 bar
  • Symbol
    00991460
  • Noise level
    83 dB(A)
  • Selection of additional function
    With pneumatic muffler
  • Type of mounting
    Screw-in
  • Ambient temperature
    -20 °C ... 75 °C
  • Information on operating and pilot media
    Operation with oil lubrication possible (required for further use)
  • Product weight
    160 g
  • Standard flow rate exhaust 6-> 0 bar
    4680 l/min
  • Operating medium
    Compressed air as per ISO 8573-1:2010 [7:-:-]
  • Nominal width
    11 mm
  • Type code
    SEU
  • Standard nominal flow rate exhaust air 6->5 bar
    2280 l/min
  • Housing material
    Die-cast aluminum
  • Temperature of medium
    -20 °C ... 75 °C
  • Valve function
    Quick exhaust
  • Pneumatic connection 2
    G3/8
  • Standard nominal flow rate pressurization 6->5 bar
    2880 l/min
  • Mounting position
    Any
  • Seals material
    NBR

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
